Lenovo 7XH7A02683 Thinksystem SR630 X8ML2/X16 PCIE Lp+lp Riser 1 KIT

Lenovo 7XH7A02683 Riser Kit

Overview

The Lenovo 7XH7A02683 is a PCIe riser kit designed to expand connectivity options within specific Lenovo server chassis. This mounting kit enables the installation of additional PCIe cards, such as network adapters or storage controllers, directly into the server's motherboard architecture. It is essential for configurations requiring enhanced I/O capabilities beyond the standard onboard interfaces. The 7XH7A02683 is engineered for reliable integration into the ThinkSystem SR630 platform, providing a stable physical interface for expansion cards.

Compatibility

This riser kit is specifically engineered for the Lenovo ThinkSystem SR630 server. It provides the necessary physical mounting and electrical interface (PCIe) to support compatible expansion cards within this server model. Ensure your intended PCIe card is also compatible with the ThinkSystem SR630's internal layout and power delivery before installation.

Installation Notes

The Lenovo 7XH7A02683 kit includes components for mounting PCIe cards. The dimensions of 11.50 x 10.00 x 2.00 inches (L x W x H) indicate the physical space required within the server chassis. Installation involves securing the riser bracket and connecting it to the motherboard's PCIe slot. Refer to the ThinkSystem SR630 server documentation for detailed installation procedures and any specific torque or handling requirements for PCIe components.
