Lenovo 7D1SA005WW DB630S 96P (32G Optics) 2 PS Rail KIT

Lenovo 7D1SA005WW DB630S 96P (32G Optics) 2 PS Rail Kit

Overview

The Lenovo 7D1SA005WW is a purpose-built rail kit for the DB630S 96-port 32G fiber channel switch, configured with dual power supply support and 32G optics. At 50 lb, this is a dense infrastructure component — the rail kit handles the mechanical burden of rack integration for a switch chassis that would otherwise require custom mounting or unsupported shelf solutions. If you are deploying or expanding a DB630S-based SAN fabric in a standard 19-inch rack environment, the 7D1SA005WW provides the manufacturer-matched mounting solution for that specific chassis and power configuration.

Compatibility

Designed specifically for the Lenovo DB630S 96-port Fibre Channel switch in the 32G optics / dual power supply configuration. This rail kit is matched to that chassis variant — do not use with single-PS DB630S builds or alternate DB-series switches, as chassis depth, weight distribution, and mounting points differ across configurations. Verify your DB630S part number confirms the dual-PS and 32G optics bill of materials before ordering. For rack planning across your broader network switching infrastructure, confirm your rack's usable depth and rail slot pitch against Lenovo's chassis specifications prior to installation.

Installation Notes

At 50 lb, the DB630S chassis demands a two-person install — single-technician rack insertion at this weight creates both safety and equipment risk. Confirm your rack's weight capacity for the target U position before sliding the chassis; bottom-heavy loading is standard practice for chassis this size. The rail kit is matched to the dual-PS variant, so ensure both power supply bays are populated before final rack seating to avoid rebalancing the chassis post-install. Consult Lenovo's DB630S hardware installation guide for torque specifications on rail bracket fasteners and cable management routing specific to the 96-port configuration.
