Lenovo 4X97A80417 SR650 V2 2.5 MID BP Sas/sata CBL V2

Lenovo 4X97A80417 SR650 V2 2.5-Inch Mid Backplane SAS/SATA Cable

Overview

The Lenovo 4X97A80417 is a factory-replacement SAS/SATA cable assembly designed for the ThinkSystem SR650 V2 server platform, specifically supporting the 2.5-inch mid backplane configuration. If you're rebuilding, repairing, or expanding storage connectivity inside an SR650 V2 chassis, this is the OEM cable that belongs in that slot — not a generic third-party assembly that may compromise signal integrity or void service agreements on your server.

The cable supports both SAS and SATA interfaces, meaning it accommodates mixed drive populations within the mid backplane zone of the SR650 V2. Whether you're running SAS HDDs for high-throughput sequential workloads or SATA SSDs for cost-effective capacity tiers, the 4X97A80417 handles both without requiring a separate cable per drive type. At 2.00 lb, it's clearly a multi-connector harness rather than a single thin cable run — consistent with the multi-drive backplane assemblies typical of 2U rack server mid-cage configurations.

Key Features

• Dual-protocol SAS/SATA support: A single cable assembly handles both SAS and SATA drive populations in the mid backplane — no need to stock separate cables if your SR650 V2 deployment mixes drive types across storage tiers.
• SR650 V2 platform-specific fit: Designed and validated for the ThinkSystem SR650 V2 chassis. Connector keying, cable routing, and length are matched to the 2.5-inch mid backplane bay geometry — a generic cable won't route or latch the same way in a 2U chassis with tight cable management.
• Factory-new genuine component: Sourced as a genuine Lenovo server part, not a third-party substitute — relevant when your SR650 V2 is under active support or when a field replacement needs to match the original bill of materials.

Integration & Compatibility

The 4X97A80417 is explicitly specified for the Lenovo ThinkSystem SR650 V2 with the 2.5-inch mid backplane configuration. Verify your chassis backplane bay layout before ordering — the SR650 V2 supports multiple backplane configurations (front, mid, rear), and the correct cable depends on which backplane zone you're cabling. Consult your SR650 V2 hardware maintenance manual or Lenovo's parts lookup to confirm the mid backplane variant matches your chassis build. Pairing with a compatible network switch or NVR storage platform downstream ensures your server's drive connectivity supports the throughput demands of enterprise IP camera recording infrastructure.

Frequently Asked Questions

Q: What server model is the Lenovo 4X97A80417 compatible with?

A: The 4X97A80417 is designed for the Lenovo ThinkSystem SR650 V2 server, specifically for the 2.5-inch mid backplane configuration. Verify your exact chassis backplane layout before ordering.

Q: Does the 4X97A80417 support both SAS and SATA drives?

A: Yes. The cable assembly supports both SAS and SATA interfaces, allowing mixed drive populations within the mid backplane zone of the SR650 V2.

Q: Is this a genuine Lenovo part or a third-party cable?

A: This is a genuine, factory-new Lenovo server component — not a third-party substitute — sourced through standard distribution channels.

Q: What does the 4X97A80417 weigh, and what does that indicate about the assembly?

A: The assembly weighs 2.00 lb, consistent with a multi-connector harness serving several drive bays across the mid backplane rather than a single-run cable.

Ted Perry

The 4X97A80417 is one of those parts you only think about when something goes wrong inside a production SR650 V2 — and when you need it, you need the right one. The SAS/SATA dual-protocol design is the key detail here: it means you're not locked into a single drive type for the mid backplane zone, which matters in environments where storage strategy evolves between initial commissioning and future capacity expansion.

Technical Highlights:

• SAS + SATA on one harness: Eliminates the need to swap cables if you transition mid-backplane drives from SATA to SAS — the 4X97A80417 handles both protocols natively.
• 2.00 lb assembly weight: Signals a substantial multi-drop harness, not a thin point-to-point run — expect multiple backplane connectors and routed cable management suited to the SR650 V2 mid-cage geometry.
• Platform-matched design: Connector placement and cable length are matched to the SR650 V2 mid backplane — forcing a generic cable into this position risks poor seating, strained connectors, or blocked airflow in a 2U chassis.

Deployment Considerations:

• Confirm your SR650 V2's exact backplane configuration before ordering — the chassis supports front, mid, and rear backplane zones, each with distinct cable part numbers; installing the wrong cable in a populated chassis means a second disassembly.
• The evidence covers interface type and weight only — for connector counts, cable length, and specific backplane compatibility codes, cross-reference the Lenovo SR650 V2 hardware maintenance manual before committing to this part in a production replacement scenario.

This cable is the right call for IT teams maintaining or expanding ThinkSystem SR650 V2 deployments in enterprise environments — particularly in security operations centers or surveillance infrastructure where SR650 V2 servers anchor high-channel NVR or video analytics workloads and storage continuity is non-negotiable.
