Lenovo 4X97A59791 SR630 V2 4X3.5 Sas/sata BP Cable KIT

Lenovo 4X97A59791 SR630 V2 4x3.5" SAS/SATA Backplane Cable Kit

Overview

The Lenovo 4X97A59791 is the OEM backplane cable kit for the ThinkSystem SR630 V2 configured with a 4x 3.5-inch SAS/SATA drive bay. If you're adding a storage backplane, swapping a failed cable assembly, or converting an SR630 V2 to a large-form-factor drive configuration, this kit supplies the exact cable routing needed — using the wrong cable or a generic substitute risks mismatch at the backplane connector and broken storage enumeration. Getting the correct Lenovo part means the drive cage, backplane, and RAID adapter all see one another cleanly on day one.

Compatibility

Designed specifically for the Lenovo ThinkSystem SR630 V2 server cable ecosystem. This kit is purpose-built for the 4x 3.5-inch SAS/SATA backplane configuration of the SR630 V2; it is not interchangeable with the SR630 (Gen 1), SR650 V2, or other ThinkSystem platforms, which use different backplane connector layouts and cable routing paths. Supports both SAS and SATA drive protocols, so it works whether the backplane feeds spinning SATA HDDs, SAS HDDs, or a mix in the same cage. If your SR630 V2 is configured for 8x 2.5-inch or NVMe backplanes, a different cable kit part number is required — verify your chassis order code before purchasing.

Installation Notes

Route cables per Lenovo's SR630 V2 hardware maintenance guide for the 4x 3.5-inch bay configuration. Ensure the server is fully powered down and discharged before handling the backplane connector. The kit ships at 0.55 lb and fits within the 9.50 × 6.00 × 2.20 in envelope — confirm adequate cable management clearance in the chassis before seating. No special tooling is specified beyond standard server maintenance practice.
