Weight:
3.95 lb
Dimensions:
4.70 x 5.00 x 4.70 in (L x W x H)
Unspsc Code:
24102001
Feature:
4-Post Tool-less Rail Kit
Form Factor:
1-Socket (1S) Rack Short-depth form factor, 561mm (22 inches) EIA rack depth
Gpu:
NVIDIA Quadro T1000 / T400 PCIe Active GPU
RAM:
Four DIMM sockets supporting Lenovo TruDDR5 DIMMs at 4400 MHz (Xeon processors) or 4400 MHz (Pentium processors). Support ECC UDIMMs.
Raid:
Supports a SAS HBA or RAID adapter for hardware RAID functionality 12Gb SAS/SATA/RAID support PCIe 3.0 and PCIe 4.0 adapters Intel VROC 6.x SW RAID CFF RAID adapters
Cooling:
Four non-hot-swap system fans
Networking:
2x 1GbE Onboard Ethernet ports (Broadcom BCM5720) Port 1 allows remote connectivity to the XCC management controller
Pcie Slots:
Riser dependent x16 PCIe riser: slot2: Optional PCIe Gen5 x16 slot for a GPU x16/x8 PCIe riser: slot1: PCIe Gen4 x8 in x8 (LP); slot2: PCIe Gen4 x8 in x16 slot (LP)
Front I/O:
Power button & LED Thermal sensor One USB 3.2 G1 (5 Gb/s) port One USB 2.0 port (also supports XClarity Mobile connectivity for local systems management)
Rear I/O:
2x USB 3.2 G1 (5 Gb/s) ports 1x VGA video 1x RJ-45 systems management 2x RJ-45 GbE network ports 1x serial port
Components:
Specification
Machine Type:
7DCM - 1 year warranty 7DCL - 3 year warranty
Chipset:
Intel Raptor Lake PCH-S C266
Memory Maximum:
Up to 128 GB using 4x 32 GB UDIMMs.
Memory Protection:
Error-correcting code (ECC)
Storage Controller:
Software RAID (RAID level 0, 1, 5, and 10): Intel VROC SATA RAID 12 Gb SAS/SATA RAID adapters 12 Gb SAS/SATA host bus adapters CFF RAID adapters
Optical Drive Bays:
No support. Use an external optical drive.
Tape Drive Bays:
No support
Hot-Swap Parts:
Hard drives and hot-swap power supplies
Security Features:
Power-on password, administrator's password, Trusted Platform Module, supporting TPM 2.0. Optional lockable front bezel for physical security.
Operating Systems Supported:
Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi. See the Operating system section for specifics.
Machine Type/Model:
Description
7Dclcto1Ww:
ThinkSystem SR250 V3 – 3-year base warranty
7Dcmcto1Ww:
ThinkSystem SR250 V3 – 1-year base warranty
Feature Code:
Description
Bwm2:
SR250 V3 3.5" Chassis Base
Bwm1:
SR250 V3 2.5" Chassis Base
Model:
Description
7Dcla03Scn:
N
7Dcla040Ap:
N
7Dcla009Ap:
N
7Dcla00Cap:
N
7Dcla03Wap:
N
7Dcla031Ap:
N
7Dcla033Ap:
N
7Dcla042Ap:
N
7Dcla043Ap:
N
7Dcla03Xap:
N
7Dcla00Aap:
N
7Dcla00Eap:
N
7Dcla03Vap:
N
7Dcla02Yap:
N
7Dcla03Uap:
N
7Dcla03Yap:
N
7Dcl100Jap:
N
7Dcla05Pap:
N
7Dcla044Ap:
N
7Dcla00Dap:
N
7Dcla00Bap:
N
7Dcla03Tap:
N
7Dcla032Ap:
N
7Dcla03Zap:
N
7Dcla041Ap:
N
7Dcla05Rap:
N
7Dcl100Map:
N
7Dcl100Kap:
N
7Dcl100Lap:
N
7Dcla05Qap:
N
7Dcla015Cn:
N
7Dcla016Cn:
N
7Dcla010Au:
N
7Dcla011Au:
N
7Dcla012Au:
N
7Dcla00Vau:
N
7Dcla00Zau:
N
7Dcla00Wau:
N
7Dcla00Yau:
N
7Dcla05Bau:
Y
7Dcla05Eau:
Y
7Dcla05Cau:
Y
7Dcla05Gau:
Y
7Dcla05Fau:
Y
7Dcla05Dau:
Y
7Dcla00Xau:
N
7Dcma00Bbr:
N
7Dcma00Abr:
N
7Dcl100Tbr:
N
7Dcla014Br:
N
7Dcla01Hbr:
N
7Dcla01Jbr:
N
7Dcla01Fbr:
N
7Dcla01Gbr:
N
7Dcla01Nbr:
N
7Dcla013Br:
N
7Dcla03Dbr:
N
7Dcl1007Br:
N
7Dcla03Ebr:
N
7Dcl1006Br:
N
7Dcla06Bbr:
N
7Dcl100Cbr:
N
7Dcl100Dbr:
N
7Dcl100Sbr:
N
7Dcl100Pbr:
N
7Dcl100Ubr:
N
7Dcla04Ubr:
Y
7Dcl100Ybr:
N
7Dcla06Cbr:
N
7Dcla038Ea:
N
7Dcla039Ea:
N
7Dcla00Kea:
N
7Dcla00Mea:
N
7Dcla00Lea:
Y
7Dcla00Pea:
N
7Dcl100Eea:
Y
7Dcla00Rea:
N
7Dcla00Nea:
N
7Dcla034Ea:
N
7Dcla00Fea:
N
7Dcla00Uea:
N
7Dcla00Gea:
N
7Dcla035Ea:
N
7Dcla03Aea:
N
7Dcla037Ea:
N
7Dcla00Jea:
N
7Dcla00Tea:
N
7Dcla00Qea:
N
7Dcla00Sea:
N
7Dcla036Ea:
N
7Dcla03Bea:
N
7Dcla00Hea:
N
7Dcla03Cea:
N
7Dcl100Fea:
Y
7Dcl100Gea:
Y
7Dcl100Hea:
Y
7Dcla04Yea:
Y
7Dcla04Xea:
Y
7Dcla02Xsg:
N
7Dcla01Ksg:
N
7Dcla01Lsg:
N
7Dcla03Lsg:
N
7Dcla03Nsg:
Y
7Dcla03Ksg:
N
7Dcla03Msg:
N
7Dcla02Vsg:
N
7Dcla02Wsg:
N
7Dcla01Msg:
N
7Dcla062Sg:
N
7Dcla063Sg:
N
7Dcea05Tsg:
N
7Dcla01Djp:
N
7Dcla01Ejp:
N
7Dcla018Jp:
N
7Dcla01Bjp:
N
7Dcla02Njp:
N
7Dcla026Jp:
N
7Dcla02Rjp:
N
7Dcla023Jp:
N
7Dcla028Jp:
N
7Dcla025Jp:
N
7Dcla02Pjp:
N
7Dcla056Jp:
Y
7Dcla01Cjp:
N
7Dcla02Qjp:
N
7Dcla027Jp:
N
7Dcla01Ajp:
N
7Dcla024Jp:
N
7Dcla057Jp:
Y
7Dcla01Qla:
N
7Dcla01Pla:
N
7Dcla01Rla:
N
7Dcla01Ula:
N
7Dcla01Sla:
N
7Dcla02Ela:
N
7Dcla02Cla:
N
7Dcl100Nla:
N
7Dcla05Mla:
N
7Dcla05Nla:
N
7Dcla05Lla:
N
7Dcla01Vla:
N
7Dcla02Ala:
N
7Dcla022La:
N
7Dcla02Dla:
N
7Dcla029La:
N
7Dcla01Tla:
N
7Dcl1003La:
N
7Dcl1004La:
N
7Dcl1002La:
N
7Dcl1005La:
N
7Dcla02Bla:
N
7Dcla069La:
N
7Dcla06Ala:
N
7Dcl100Ala:
N
7Dcl1009La:
N
7Dcl100Bla:
N
7Dcl100Qla:
N
7Dcl1008La:
N
7Dcl100Rla:
N
7Dcl100Vla:
N
7Dcla04Sla:
N
7Dcla04Tla:
Y
7Dcl100Xla:
N
7Dcl100Zla:
N
