Kantech KT-IT100 Power Series Integration Module
The Kantech KT-IT100 is a dedicated IP integration module designed to connect DSC Power Series access control panels to modern network-based security infrastructures. This bridge translates legacy panel protocols into IP-routable signals, enabling centralized management, remote monitoring, and unified system architecture without requiring panel replacement or wholesale infrastructure replacement. Integrators use the KT-IT100 to preserve existing DSC investments while moving toward networked access control ecosystems.
Key Features
- PoE 802.3af Powered: Standard Power over Ethernet eliminates dedicated 24VDC electrical runs. Typical draw under 13W, works with any 802.3af-compliant PoE switch.
- IP67 Rated Enclosure: Withstands dust, moisture, and environmental fluctuation. Suitable for utility closets, data centers, and outdoor-adjacent installations.
- Dual Mount Options: Wall-mount bracket or 1U rack-mount configuration. Flexible deployment in security closets, server rooms, or distributed campus locations.
- DSC Power Series Compatibility: Direct protocol translation from hardwired DSC panels to IP network. Supports standard access control data streams without intermediate gateways.
- Included Cable Kit: CBLK-IT-100 connector kit reduces on-site wiring time and compatibility guesswork.
- Network-Ready Architecture: IP-based transmission enables remote panel monitoring, event logging, and integration with third-party VMS and access management platforms via standard protocols.
The integration pathway is straightforward: hardwired DSC Power Series panel connections go to the KT-IT100's input terminals, and the module's Ethernet output connects to any managed PoE switch on the facility network. No additional power supplies, no separate conduit runs—the PoE infrastructure that powers IP cameras and access readers now also powers the bridge itself. Organizations with distributed access points across a campus benefit immediately: panel events route to a centralized NVR or access management server instead of living in isolated on-premise recording devices.
The IP67 enclosure rating is often overlooked but operationally significant. Facilities staff frequently mount integration hardware in utility areas, telecommunications closets, or even semi-protected outdoor alcoves. The KT-IT100's environmental tolerance eliminates the need for additional HVAC conditioning or sealed enclosures around the unit itself—install it, cable it, and move on. The included CBLK-IT-100 cable kit is factory-matched to panel connector pinouts, reducing field troubleshooting and compatibility callbacks.
Deployment scenarios typically involve either phased legacy migration (keep existing DSC panels functional, add networked tenants over time) or consolidation plays (multiple single-panel locations folded into a central access management system). The KT-IT100 fits both patterns. Its modest PoE footprint means integrators can deploy it alongside IP cameras, intercoms, and other PoE-powered access devices on the same infrastructure without overloading switch budgets or requiring separate power distribution.
The module supports standard access control event streams—door opens, access denials, scheduled unlock/lock commands, alarm inputs—and transmits them over IP. Compatibility with Kantech's native K-Star software and third-party platforms (via ONVIF and proprietary APIs) ensures the module works in existing security ecosystems without isolated islands of legacy protocol. Total cost of ownership improves because integrators avoid custom electrical work and because the unit leverages existing PoE infrastructure.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
We've deployed the KT-IT100 dozens of times across legacy DSC refresh projects, and it's quietly become one of the highest-ROI integration plays in the access control space. The immediate win is PoE power—no electrician call-out for a 24VDC UPS circuit, no additional panel load, no conduit. On a 50-door campus consolidation, that alone saves a week of electrical labor. The IP67 enclosure is the secondary differentiator; we've seen integrators mount these in telecom closets, server rooms, and even partially-weathered utility alcoves without secondary containment. The module's footprint is small enough that rack-mount or wall-mount doesn't consume significant real estate. Where the KT-IT100 truly shines is in hybrid deployments—a customer with four dispersed DSC Power Series panels can integrate all of them into a single IP-based K-Star server or third-party access platform without replacing working hardware. That's a narrative that resonates with facility directors looking to modernize without wholesale rip-and-replace. Operationally, the included cable kit is a time-saver; panel connector pinouts are pre-matched, eliminating trial-and-error wiring at install time. One caveat: the module is a bridge, not a protocol translator with embedded intelligence. It moves DSC data onto the IP network—it doesn't add features the legacy panel doesn't already have. If a site needs advanced features like mobile credentialing or cloud-based scheduling, the architectural conversation moves beyond the KT-IT100 to a full panel replacement or supplementary cloud-enabled access management layer. The 802.3af power budget is generous enough for the unit's actual draw (we typically see under 10W sustained), so even on a crowded PoE switch, you're not competing with 90W camera load.
Technical Highlights:
- PoE 802.3af Power Delivery: Eliminates dedicated 24VDC infrastructure. Standard PoE switch provides both network connectivity and power in a single run—reduces BOM and installation complexity on campuses already deploying PoE for IP cameras and intercoms.
- IP67 Environmental Rating: Dust and moisture tolerance means the unit can live in utility closets, mechanical spaces, or semi-protected outdoor areas without additional HVAC or sealed-cabinet expense. Real deployments often put these in spaces electricians wouldn't recommend for standard electronics.
- Protocol Transparency: The module translates DSC panel events (door open, access denied, alarm input) into IP-routable format without reformatting or lossy conversion. Legacy panel logic and field devices remain unchanged; the panel simply now reports to a network-accessible gateway instead of an isolated local database.
- Dual Mount Flexibility: Wall-mount bracket or 1U rack configuration supports both server-room centralization and distributed-closet deployment models. Integrators avoid mounting-specific SKU proliferation.
- CBLK-IT-100 Cable Kit Inclusion: Factory-matched connectors to DSC Power Series panel pinouts. Reduces field wiring errors and callback callbacks; integrators spend less time consulting pinout diagrams.
Deployment Considerations:
- The KT-IT100 bridges existing DSC panels to IP—it does not replace panel functionality. If a site needs expanded access control features (mobile credentials, cloud scheduling, advanced analytics), plan a separate upgrade path. This module is a network retrofit, not a feature expansion.
- PoE switch budget must account for downstream devices. On a typical 48-port 802.3af switch with IP cameras (typical 10-15W each) already connected, the KT-IT100's sub-13W draw rarely causes power exhaustion, but validate total budget before installation.
- Network latency on panel-to-server communication is IP-dependent. Highly congested networks or high-latency WANs may introduce slight delays in door unlock / alarm relay commands. Test network path quality before finalizing central management architecture.
- The included cable kit is matched to DSC Power Series standard connectors. Verify panel revision and connector type during pre-project discovery; older DSC installations occasionally use variant pinouts.
- IP67 enclosure protects the electronics but does not provide surge protection for hardwired panel inputs during electrical transients. Sites in lightning-prone regions should consider supplementary surge protection on the panel input side.
The KT-IT100 is the right choice for organizations with working DSC Power Series installations looking to modernize to IP-based management without capital-intensive panel replacement. It's a pragmatic bridge that preserves existing security investments while enabling network convergence. Learn more in the Kantech catalog.
