Image Sensor:
Approx. 1/2.7 type CMOS image sensor
Effective pixels:
Approx. 5.2 megapixels, 2688(H)×1944(V)
Minimum Illumination:
Color : 0.3 lx, BW: 0.12 lx (50IRE, F2.0, Maximum shutter: Off (1/30s), AGC: 11); BW : 0 lx (50IRE, F2.0, Maximum shutter: OFF (1/30 s), AGC: 11, when the IR LED is lit); Color : 0.019 lx, BW: 0.0075 lx (50IRE, F2.0, Maximum shutter: max. 16/30s, AGC
White Balance:
ATW1/ ATW2/ AWC
Maximum Shutter:
[30fps mode] Max. 1/10000 s to Max. 16/30 s; [25fps mode] Max. 1/10000 s to Max. 16/25 s
Intelligent Auto:
On / Off
Super Dynamic:
On / Off, the level can be set in the range of 0 to 31.
Dynamic Range:
Max.102 dB (Super Dynamic: On, Level: 31)
Adaptive Black Stretch:
The level can be set in the range of 0 to 255.
Back Light Compensation/High Light Compensation:
BLC/ HLC/ Off, The level can be set in the range of 0 to 31.; The level can be set in the range of 0 to 31.; (only when Super Dynamic/ Intelligent auto: Off)
Fog Compensation:
On / Off, The level can be set in the range of 0 to 8.; (only when Intelligent auto / auto contrast adjust: Off)
Maximum Gain (AGC:
The level can be set in the range of 0 to 11.
Color/BW (ICR:
Off/ On (IR Light Off)/ On (IR Light On)/ Auto1 (IR Light Off)/ Auto2 (IR Light On)/ Auto3 (SCC)
IR LED Light:
High/ Middle/ Low/ Off; Maximum irradiation distance: 20 m {Approx. 65 ft}
Digital Noise Reduction:
The level can be set in the range of 0 to 255.
Video Motion Detection (VMD:
On / Off, 4 areas available
Scene Change Detection(SCD:
On / Off, 1 areas available
Privacy Zone:
On / Off (up to 8 zones available)
VIQS:
On / Off, Up to 8 zones available
Image Rotation:
0° (Off)/ 90°/ 180° (Upside-down)/ 270°
Camera Title (OSD:
On / Off, Up to 20 characters (alphanumeric characters, marks)
Focal Length:
3.2 mm{1/8 inches}
Optical Zoom:
1x
Extra optical zoom:
1.0x - 1.3x(when resolution is 1920x1080)
Digital (electronic) zoom:
Choose from 3 levels of x1, x2, x4
Angular Field of View:
[16 : 9 mode] *[4:3 mode] is not supported. / Horizontal : 100°, Vertical : 54°
Maximum Aperture Ratio:
1 : 2.0
Focusing Range:
1 m {39-3/8 inches} – ∞
Detect (25ppm / 8ppf:
43.0 m / 141.0 ft
Observe (62.5ppm / 19ppf:
17.2 m / 56.4 ft
Recognize (125ppm / 38ppf:
8.6 m / 28.2 ft
Identify (250ppm / 76ppf:
4.3 m / 14.1 ft
Adjusting Angle:
Horizontal (PAN) angle: -175 °– +175 °, Vertical (TILT) angle: -30 °– +80 °; Azimuth (YAW) angle: ±100°
Camera Control:
Brightness
GUI / Setup Menu Language:
English, Italian, French, German, Spanish,; Portuguese, Russian, Chinese, Japanese
Network IF:
10Base-T / 100Base-TX,; RJ45 connector
Resolution H.265/H.264:
[16:9 mode(2688x1520 30fps mode)], [16:9 mode(2688x1520 25fps mode)]; 2688×1520, 1920×1080, 640×360, 320×180; [16:9 mode(30fps mode)], [16:9 mode(25fps mode)]; 2560×1440, 1920×1080, 640×360, 320×180; *[4:3 mode] is not supported.
H.265/H.264:
[Transmission Mode] Constant bit rate / VBR / Frame rate / Best effort; [Transmission Type] Unicast port(AUTO) / Unicast port(MANUAL) / Multicast; [Max. frame rate foreach stream]; Stream(1) : 2688x1520(30fps) / 2560x1440(30fps) / 1920x1080(30fps); S
JPEG:
[Image Quality]; 10 steps
Smart Coding:
GOP(Group of pictures) control: On(Frame rate control)/ On(Advanced)/ On(Mid.)/ On(Low)/ Off; *Frame rate control and Advanced are only available with H.265.; AUTO VIQS: On/ Off
Audio Compression:
-
Audio Transmission Mode:
-
Supported Protocol:
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SMTP, DNS, NTP, SNMP,v1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ,MQTT,LLDP; IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, ICMP, ARP,
No. of Simultaneous Users:
Up to 14 users; (Depends on network conditions)
Secure:
Device Certificate GlobalSign® pre-installed,; User authentication,Host authentication,; HTTPS, 802.1X Support, Data encryption
SDXC/SDHC/SD Memory Card (Option:
H.265 recording: Manual REC / Alarm REC (Pre/Post) / Schedule REC; Compatible SDXC/SDHC Memory Card:; microSDXC memory card : 64 GB, 128GB, 256GB, 512GB; microSDHC memory card : 4GB, 8GB, 16GB, 32GB; microSD memory card : 2GB
Mobile Terminal Compatibility:
iPad, iPhone,; AndroidTM terminals
ONVIF® Profile:
G / S / T
Alarm Source:
VMD alarm,; SCD alarm,; Command alarm
Alarm Actions:
SDXC/SDHC/SD memory recording, E-mail notification,; HTTP alarm notification, Indication on browser,; TCP alarm notification output
Monitor Output (for Adjustment:
-
Audio input:
-
Audio Output:
-
External I/O Terminals:
-
Safety:
UL (UL60950-1), c-UL (CSA C22.2 No.60950-1), CE, IEC60950-1
EMC:
FCC (Part15 ClassA), ICES003 ClassA, EN55032 ClassB, EN55035
Power Source and Power Consumption:
PoE (IEEE802.3af compliant) Device:; DC48 V 110 mA, Approx. 5.3 W (Class 2 device)
Ambient Operating Temperature:
-30 °C to +50 °C (-22 °F to +122 °F); {Power On range: -20 °C to +50 °C (-4°F to +122 °F)}
Ambient Operating Humidity:
10 to 100 % (no condensation)
Anti-Condensation System:
Temish element
Water and Dust Resistance:
IP66 (IEC 60529), Type 4X (UL50E), NEMA 4X compliant
Shock Resistance:
IK10 (IEC 62262)
Wind Resistance:
Up to 40 m/s {approx. 89 mph}
Dimensions:
ø109 mm (W) x 62 mm (H) {ø4-9/32 inches × 2-7/16 inches (H)}; Dome radius 30.5 mm {1-3/16 inches}
Mass (Approx:
270 g {0.60 lbs.}
Finish:
Main body : Aluminum die cast / Polycarbonate resin, i-PRO white; Outer fixing screws : Stainless steel (Corrosion-resistant treatment); Dome cover : Polycarbonate resin, Clear
