APC by Schneider Electric Hyperpod Door - Door Frame 5-6FT Aisle - FS-DR-2002-B

APC by Schneider Electric FS-DR-2002-B Hyperpod Door Frame for 5–6 Ft Aisle Containment

Overview

The APC by Schneider Electric FS-DR-2002-B is a black steel door frame designed for the Hyperpod hot/cold aisle containment system in data center and server room deployments. At 775 mm wide by 520 mm deep and 2,050 mm tall, the FS-DR-2002-B fits standard 5-to-6-foot aisle widths, providing a structurally consistent entry point for contained aisles without requiring custom fabrication. If your row layout falls outside that range, verify aisle width before ordering — containment door frames are not field-adjustable.

Key Features

• UL, cUL, and CE Listed: All three certifications are present on the FS-DR-2002-B, which matters for data center fit-out projects subject to electrical and building inspection — many facilities require listed components throughout the mechanical infrastructure, not just the active equipment.
• 775 mm Clear Opening Width: At 775 mm (approximately 30.5 inches), the frame accommodates standard aisle-containment door panels and provides adequate clearance for equipment transport through the aisle during maintenance windows.
• 2,050 mm Frame Height: The 2,050 mm (approximately 80.7 inches) height aligns with standard floor-to-ceiling containment systems and full-height rack rows, avoiding gaps at the top of the frame that would compromise hot/cold air separation.
• Black Powder-Coat Finish: The black finish integrates visually with standard black rack infrastructure — not a functional spec, but relevant when aesthetic consistency matters in customer-facing or co-location deployments.
• Designed for 5–6 Ft Aisles: The frame is dimensioned specifically for this aisle width range. Narrower or wider aisles require a different Hyperpod door frame variant — confirm your aisle measurement against the 775 mm opening before procurement.
• 136 kg Packaged Weight: At 136 kg shipping weight, plan for appropriate receiving and staging resources. Two-person lift minimum; confirm freight delivery to loading dock is available at your site.

Integration and Compatibility

The FS-DR-2002-B (often searched as FS DR 2002 B) is a component of the APC Hyperpod aisle containment system. It is designed to integrate with compatible Hyperpod door panels, ceiling tiles, and containment brackets from the same product family. Verify compatibility with your existing Hyperpod generation before ordering — APC has released multiple containment system iterations, and door frame dimensions and mounting interfaces vary between generations. This frame is not a standalone product; it requires compatible door panel hardware to function as a complete aisle entry point.

Frequently Asked Questions

Q: What aisle width does the FS-DR-2002-B fit?

A: The FS-DR-2002-B is designed for 5-to-6-foot wide aisles. The frame opening is 775 mm (approximately 30.5 inches) wide. Verify your aisle measurement before ordering — this frame is not adjustable in the field.

Q: What certifications does the FS-DR-2002-B carry?

A: The FS-DR-2002-B is listed to UL, cUL, and CE standards.

Q: What is the warranty on the FS-DR-2002-B?

A: APC provides a 1-year manufacturer warranty on the FS-DR-2002-B.

Q: How heavy is the FS-DR-2002-B when shipped?

A: The packaged shipping weight is 136 kg. Plan for freight delivery to a loading dock and at minimum a two-person lift for staging and installation.

Q: Is the FS-DR-2002-B compatible with all APC Hyperpod systems?

A: The FS-DR-2002-B is part of the APC Hyperpod aisle containment family, but APC has released multiple containment system generations with varying mounting interfaces. Confirm compatibility with your specific Hyperpod generation before ordering.

Karl Wilson

The FS-DR-2002-B is a straightforward structural component, but the 775 mm opening dimension is the spec that drives procurement decisions here — if your aisle doesn't fall in the 5-to-6-foot range, this frame won't work and you'll be returning freight that weighs 136 kg packaged. Measure first.

Technical Highlights:

• 775 mm Opening Width: Sized for 5–6 ft aisle containment deployments; aligns with standard hot/cold aisle configurations in mid-to-large data center row layouts.
• 2,050 mm Frame Height: Full-height containment alignment at approximately 80.7 inches — consistent with standard rack heights and minimizes bypass airflow at the top of the aisle entry.
• UL / cUL / CE Listed: All three listings are present, which satisfies inspection requirements for data center infrastructure buildouts in both US and European facilities.

Deployment Considerations:

• At 136 kg packaged, this ships as freight — confirm your site has a loading dock or appropriate lift equipment before scheduling delivery. It is not a small-parcel item.
• The FS-DR-2002-B requires compatible Hyperpod door panels and ceiling components to function as a complete aisle entry. It is not a standalone containment solution — budget and spec the full system before ordering individual components.

Best fit for data center fit-out projects or raised-floor server room builds where a 5-to-6-foot hot or cold aisle is being retrofitted with containment infrastructure and inspection-listed components are required by the facility.
