APC by Schneider Electric Hyperpod Accessory - Aisle Crossover Tray 5-6FT Aisle - FS-AC-4007-B

APC by Schneider Electric FS-AC-4007-B Hyperpod Aisle Crossover Tray, 5–6 Ft Aisle

Overview

The APC by Schneider Electric FS-AC-4007-B is a structured cable-management crossover tray engineered for Hyperpod aisle containment deployments in data center and server room environments. Spanning 1,970 mm (roughly 77.5 inches) in depth and 375 mm (14.75 inches) in width, this tray bridges hot-aisle or cold-aisle containment gaps across 5–6 foot aisle widths — the standard span found in most enterprise row-based server deployments. If you're building or retrofitting an aisle containment system and need a code-listed overhead bridge that keeps cabling organized without compromising the containment envelope, the FS-AC-4007-B (often searched as FS AC 4007 B) belongs on your BOM.

Key Features

• 1,970 mm Span for 5–6 Ft Aisles: The tray's 1,970 mm (approx. 77.5 in) depth is sized to bridge standard 5–6 foot data center aisles cleanly — no cutting, no field-fabrication. A properly sized crossover eliminates improvised cable runs that defeat containment airflow integrity.
• 375 mm Tray Width: At 375 mm (14.75 in) wide, the FS-AC-4007-B provides enough runway to organize high-density cable bundles crossing the aisle overhead without forcing sharp bend radii that degrade copper or fiber performance.
• 300 mm Profile Height: The 300 mm (11.8 in) height keeps the crossover tray within the standard overhead containment clearance envelope, allowing it to integrate with APC Hyperpod containment hardware without requiring ceiling modifications in most raised-floor or overhead-cable facilities.
• Black Finish, Commercial-Grade Construction: The black finish matches standard APC Hyperpod infrastructure and reduces visual clutter in customer-facing or audited data center environments. Commercial-grade powder coat resists corrosion in the slightly elevated humidity ranges common in contained hot aisles.
• UL and cUL Listed, CE Marked: UL, cUL, and CE certifications cover both US and Canadian installations plus EU deployments — relevant if you're standardizing across geographically distributed facilities. Most enterprise facility managers and AHJs require UL listing for overhead cable infrastructure; this tray delivers it without a variance.
• Lightweight Packaging at 24 kg: At 24 kg (52.9 lbs) packaged, the FS-AC-4007-B is manageable for a two-person overhead installation without specialized lift equipment — a practical consideration when working in occupied data center rows with limited access.
• 1-Year Manufacturer Warranty: Covered by a 1-year manufacturer warranty, consistent with APC's structural accessory line. For long-horizon facilities projects, confirm whether extended service contracts apply at the system level.

Integration and Compatibility

The FS-AC-4007-B is designed as a Hyperpod accessory, which means it integrates within APC's modular aisle containment ecosystem. Before ordering, verify your aisle width falls in the 5–6 foot range — APC offers alternate crossover tray models for narrower and wider aisles, and the wrong span will not seat correctly against containment end panels. The package dimensions (2,070 mm × 375 mm × 300 mm) require a freight-capable receiving dock; standard parcel delivery is not appropriate for this item. Plan staging space accordingly prior to installation.

Frequently Asked Questions

Q: What aisle width is the FS-AC-4007-B designed for?

A: The FS-AC-4007-B is sized for 5–6 foot aisles. Its 1,970 mm (approximately 77.5 inch) depth spans that range within the APC Hyperpod containment system. If your aisle is outside this range, APC offers other crossover tray models matched to different spans.

Q: What certifications does the FS-AC-4007-B carry?

A: The FS-AC-4007-B is UL Listed, cUL Listed (for Canadian installations), and CE marked for EU deployments — suitable for most enterprise facilities requiring code-listed overhead cable infrastructure.

Q: What is the warranty on the FS-AC-4007-B?

A: APC covers the FS-AC-4007-B with a 1-year manufacturer warranty.

Q: Is special lifting equipment needed to install the FS-AC-4007-B?

A: The packaged weight is 24 kg (approximately 52.9 lbs). A standard two-person overhead installation is typically feasible without dedicated lift equipment, though working conditions in occupied data center rows should be assessed on-site before committing to an installation approach.

Q: Can this crossover tray ship via standard parcel carriers?

A: The package dimensions are 2,070 mm × 375 mm × 300 mm — this requires freight shipping, not standard parcel delivery. Ensure your facility has an appropriate receiving dock and staging area before placing the order.

James Everett

When I spec the FS-AC-4007-B into a Hyperpod containment project, the dimension I anchor on first is the 1,970 mm span — that's the number that tells you whether this tray actually fits your aisle without any field modification. In a 5–6 foot hot-aisle containment row, getting the crossover tray wrong by even a few inches means you're either fighting gaps in the containment envelope or forcing the tray to overhang end panels, and either problem undermines the whole airflow argument for containment in the first place.

Technical Highlights:

• 1,970 mm Span: Precisely sized for 5–6 foot aisles — fits APC Hyperpod containment geometry without field cutting or custom adapters, preserving installation schedule on live data center rows.
• 375 mm Tray Width: Wide enough to route high-density patch bundles overhead without tight bends, reducing signal-degrading stress on both copper and fiber runs crossing the aisle.
• UL / cUL / CE Certified: Covers US, Canadian, and EU facility compliance requirements in a single SKU — useful when you're standardizing infrastructure across multi-site enterprise deployments that span jurisdictions.

Deployment Considerations:

• The packaged unit ships at 2,070 mm in length and 24 kg — freight delivery only. Schedule dock availability and aisle staging before the equipment arrives; trying to maneuver a nearly 7-foot tray through a live data hall without a plan creates unnecessary risk to adjacent hardware.
• This tray is a Hyperpod-ecosystem component. Verify your existing containment hardware is Hyperpod-compatible before ordering — mixing containment systems from different product lines typically produces mounting interface mismatches that require custom brackets and negate the install-time advantage of modular systems.

The FS-AC-4007-B is the right call for enterprise data centers standardized on APC Hyperpod containment where 5–6 foot aisles are the dominant row geometry and facility management requires UL-listed overhead cable infrastructure as a baseline compliance requirement.
