APC by Schneider Electric Hyperpod Roof - Roof Filler Panel SET 6FT Aisle - FS-RF-1002-B

APC by Schneider Electric FS-RF-1002-B Hyperpod Roof Filler Panel Set, 6FT Aisle

The APC by Schneider Electric FS-RF-1002-B is a roof filler panel set designed specifically for the Hyperpod aisle containment system in 6-foot aisle configurations. Filler panels are a non-negotiable finishing component in hot aisle/cold aisle containment deployments — gaps in the roof plane bleed conditioned air into the return plenum and quietly undercut the thermal separation your containment system was built to maintain. The FS-RF-1002-B closes those gaps, completing the roof seal across the full 2,392 mm (approximately 94 inches) depth of a 6FT aisle containment run.

Overview

Aisle containment without a properly sealed roof is an incomplete system. Hot exhaust migrates upward, and any unsealed panel position in the roof plane creates a mixing zone that raises both inlet temperatures and cooling overhead. The FS-RF-1002-B is the correct filler panel set for Hyperpod roof assemblies where a standard rack-width module leaves a gap — filling that gap with a manufacturer-matched panel maintains the integrity of the containment envelope rather than relying on makeshift solutions that distort airflow. At 132 mm high and 60 mm wide, each panel is dimensioned to fit the Hyperpod roof frame geometry without field modification.

Key Features

• Full-Depth Coverage at 2,392 mm: The panel set spans the complete 2,392 mm depth of a 6FT aisle containment bay, which means you get a continuous sealed surface across the entire roof run — no partial fill, no gaps left to tape or improvise around.
• Precision Panel Geometry (132 mm H × 60 mm W): The 132 × 60 mm cross-section is matched to the Hyperpod roof frame profile. Correct geometry matters here: a panel that is even slightly oversized forces the frame out of square; undersized panels leave thermal bypass gaps. Manufacturer-dimensioned parts eliminate that fitment risk.
• Black Finish for Visual Consistency: The black color matches the standard Hyperpod aisle containment hardware, keeping the containment structure visually clean in customer-facing or audited data center environments where appearance and professionalism matter alongside thermal performance.
• UL, cUL, and CE Listed: Certification to UL, cUL (Canadian UL), and CE (European conformity) means this panel can be specified into North American and EU facilities without triggering compliance questions from facilities management or building inspectors. For sites with strict acceptance criteria on installed components, that listing removes a friction point.
• Lightweight Set Construction at 10 kg: The full set weighs 10 kg (approximately 22 lbs), which means a single technician can handle installation without a lift assist — relevant in dense or narrow aisle environments where maneuvering overhead is awkward.
• 1-Year Manufacturer Warranty: Covered under APC by Schneider Electric's standard 1-year manufacturer warranty. For a passive structural component like a filler panel, warranty coverage primarily matters if a panel arrives damaged or shows a dimensional defect that prevents proper fit — return path is documented.

Integration and Compatibility

The FS-RF-1002-B is designed for the APC Hyperpod aisle containment system in 6FT aisle configurations. Before ordering, confirm your aisle width matches the 6FT designation — Hyperpod panels are dimensioned per aisle size and the 2,392 mm depth spec is the key fitment constraint. This panel set is a passive structural component and requires no electrical connection, network integration, or software configuration. Installation is mechanical only, into the existing Hyperpod roof frame. If your containment deployment includes variable-depth bays or mixed aisle widths, verify the specific roof filler SKU required for each bay size against the Hyperpod configuration guide before procurement.

Frequently Asked Questions

Q: What aisle containment system does the FS-RF-1002-B fit?

A: The FS-RF-1002-B is designed for the APC Hyperpod aisle containment system in 6FT aisle configurations. It is not a universal filler panel — verify your aisle designation before ordering.

Q: What are the panel dimensions for the FS-RF-1002-B?

A: Each panel in the set measures 2,392 mm deep × 132 mm high × 60 mm wide. These dimensions are matched to the Hyperpod 6FT roof frame geometry.

Q: What certifications does the FS-RF-1002-B carry?

A: The FS-RF-1002-B is UL, cUL, and CE listed, covering North American (US and Canada) and European facility compliance requirements.

Q: What is the warranty on the FS-RF-1002-B?

A: APC by Schneider Electric covers the FS-RF-1002-B with a 1-year manufacturer warranty.

Q: Does the FS-RF-1002-B require any electrical or network connections?

A: No. This is a passive structural panel. Installation is mechanical only — no wiring, no power, no software configuration required.

Q: How much does the full FS-RF-1002-B set weigh?

A: The complete set weighs 10 kg (approximately 22 lbs), which is within single-technician handling range for overhead installation.

Eden Phillips

The FS-RF-1002-B is one of those components that gets overlooked in the BOM until the containment commissioning walk-through, at which point missing roof filler panels become a same-day procurement emergency. The 2,392 mm depth on this set is the spec that ties it to the 6FT Hyperpod aisle — order the wrong depth and the panel either overhangs the frame or leaves a gap, both of which compromise the containment seal you just paid to build.

Technical Highlights:

• 2,392 mm Full-Depth Span: Covers the complete roof depth of a 6FT Hyperpod aisle bay in a single set — no splicing, no partial fill that leaves a thermal bypass strip at one end of the bay.
• UL / cUL / CE Certification: Tri-listed, which satisfies the compliance checklist for North American and EU facilities in a single SKU — no need to source a separate CE-marked variant for European sites.
• 10 kg Set Weight: Light enough for a one-person overhead install in a live aisle environment where ladder access is tight and a second technician isn't always available.

Deployment Considerations:

• Confirm aisle designation before ordering — the 6FT depth spec (2,392 mm) is non-negotiable for frame fitment. Hyperpod aisle containment systems come in multiple width configurations, and the roof filler panel sets are not interchangeable across them.
• This is a passive structural component with no active functionality. It will not show up in DCIM, BMS, or any monitoring system — thermal improvement is only measurable at the row or room level after full containment sealing is complete.

The FS-RF-1002-B is the right call for Hyperpod 6FT aisle deployments in enterprise data centers, colocation facilities, or high-density compute rooms where containment completeness is being audited — facilities where a missing roof panel is a finding, not a cosmetic issue.
