HPE G12 2SFF X4NVME U.2 BC BP KIT - P75087-B21

HPE P75087-B21 Concise Descriptor

Overview

The HPE P75087-B21 is a 2.5-inch SFF (Small Form Factor) U.2 backplane kit designed to expand NVMe storage capacity in specific HPE ProLiant server configurations. This kit enables the integration of high-speed U.2 NVMe drives, providing significant improvements in data throughput and I/O performance for demanding workloads such as databases, virtualization, and high-performance computing. It's a direct hardware upgrade path for servers that support this specific backplane configuration.

Compatibility

This backplane kit is engineered for direct installation into HPE ProLiant Gen12 servers that are configured for 2SFF (2 Small Form Factor) drive bays and support NVMe U.2 drive connectivity. It is specifically designed for the chassis architecture of these servers, ensuring a secure and reliable connection. Consult your server's QuickSpecs or hardware compatibility list for confirmation of P75087-B21 support within your specific HPE ProLiant Gen12 model.

Installation Notes

Installation requires opening the server chassis and physically connecting the backplane to the motherboard's U.2 NVMe connectors and power supply. Ensure the server is powered off and properly grounded before proceeding. The kit includes the necessary components for a single 2-drive U.2 backplane installation. Refer to the HPE server's service manual for detailed, step-by-step installation instructions and torque specifications for securing the backplane and drives.

What's in the Box

• 1x HPE 2SFF U.2 Backplane Kit (P75087-B21)
• Mounting hardware
