HPE DL560 G11 OCP1/BOX3 X2 BP CBL KIT - P61603-B21

HPE P61603-B21 Concise Descriptor

Overview

The HPE P61603-B21 is a cable kit designed for specific HPE server configurations, enabling the connection of OCP 1.0 mezzanine cards and providing a dual-bay backplane. This kit is essential for integrating specific network interface cards or other OCP modules into compatible HPE ProLiant DL560 Gen11 servers, ensuring proper data and power flow.

Compatibility

This cable kit is specifically designed for the HPE ProLiant DL560 Gen11 server platform. It facilitates the integration of OCP 1.0 mezzanine cards and a dual-bay backplane within this server model. Compatibility is limited to the specified server generation and configuration; verify your server's chassis and motherboard revision before ordering.

Installation Notes

Installation requires opening the server chassis and carefully routing cables to their respective connectors on the motherboard and OCP card. Ensure the server is powered off and properly grounded before beginning. Refer to the HPE ProLiant DL560 Gen11 server maintenance and service guide for detailed, step-by-step instructions and torque specifications for any secured components.

What's in the Box

• 1x HPE P61603-B21 OCP1/BOX3 X2 BP CBL KIT
