HPE DL380 GEN12 8SFF UMB PCIE CBL KIT - P76453-B21

HPE P76453-B21 Concise Descriptor

Overview

The HPE P76453-B21 is a PCIe cable kit designed for specific HPE server configurations. This accessory provides the necessary cabling to integrate PCIe devices, such as network interface cards or storage controllers, into compatible HPE ProLiant DL380 Gen10 Plus server platforms. Its primary function is to ensure proper electrical and physical connection for these expansion cards, enabling enhanced system functionality for demanding workloads.

Compatibility

This cable kit is specifically designed for the HPE ProLiant DL380 Gen10 Plus server series, particularly models configured with an 8 Small Form Factor (SFF) drive bay layout and requiring a PCIe cabling solution. It is intended for use with servers that support the installation of additional PCIe expansion cards via this specific cabling method. Always verify your server's exact configuration and service manual to confirm compatibility before purchase.

Installation Notes

Installation requires opening the server chassis and carefully routing the PCIe cables from the motherboard's PCIe slot to the designated backplane or riser card connections. Ensure the server is powered off and all power sources are disconnected before beginning installation. Proper cable management is crucial to avoid interference with airflow and other components. The kit includes the necessary cables for a standard PCIe device installation within the specified server models.

What's in the Box

• 1x HPE P76453-B21 PCIe Cable Kit
