HPE P57109-B21 8SFF Midtray Kit
Overview
The HPE P57109-B21 is a midtray kit designed to expand storage capacity for specific HPE ProLiant server models. This component is critical for deployments requiring increased drive density, such as those handling large datasets or requiring local storage for applications like video surveillance NVRs or data analytics platforms. Its inclusion allows for the installation of up to eight Small Form Factor (SFF) drives, enhancing the server's I/O capabilities and storage footprint without requiring a chassis swap.
Compatibility
This midtray kit is specifically designed for HPE ProLiant DL345 Gen11 servers configured with an 8SFF (Small Form Factor) drive bay arrangement. It is not compatible with other server generations or different drive bay configurations (e.g., LFF - Large Form Factor). Always verify your server's chassis and backplane configuration before ordering.
Installation Notes
Installation requires opening the server chassis and connecting the midtray to the server's backplane and power distribution. Ensure the server is powered down and properly grounded before proceeding. The kit includes necessary cabling for drive power and data connectivity to the main system board or RAID controller. Refer to the HPE ProLiant DL345 Gen11 server maintenance guide for detailed installation procedures.
What's in the Box
- 1x HPE P57109-B21 8SFF Midtray Kit
