HPE DL325 GEN12 4LFF SATA Direct CBL KIT - P81909-B21

HPE P81909-B21 Concise Descriptor

Overview

The HPE P81909-B21 is a direct-attached SATA cable kit designed to connect storage devices within compatible HPE server chassis. This accessory is critical for ensuring proper data connectivity between SATA drives and the server's motherboard or RAID controller, specifically in configurations requiring direct SATA cabling. Its purpose is to facilitate the integration of additional or replacement SATA storage within the server's internal bays.

Compatibility

This cable kit is engineered for specific HPE ProLiant DL325 Gen12 server models equipped with 4LFF (4 Large Form Factor) drive bays. It is designed to connect SATA drives directly to the server's onboard SATA controller or a compatible HPE Smart Array controller. Verify your server's internal cabling configuration and drive bay type before ordering.

Installation Notes

The HPE P81909-B21 utilizes standard SATA data connectors. Installation requires opening the server chassis and physically connecting the cable from the drive bay backplane or individual drive locations to the appropriate SATA port on the server's motherboard or RAID controller. Ensure the server is powered off and properly grounded before installation. The cable's length is optimized for internal server routing.

What's in the Box

• 1x HPE P81909-B21 SATA Direct Cable Kit
