HP Inc 79C23AA HP SmartBuy NVIDIA RTX 6000 Ada 48GB 4DP GFX

HP Inc 79C23AA NVIDIA RTX 6000 Ada 48GB Professional Workstation GPU

Overview

The HP Inc 79C23AA is an HP SmartBuy-designated professional graphics card built around the NVIDIA RTX 6000 Ada Generation GPU — a full-fat Ada Lovelace die with 18,176 CUDA cores and 48GB of GDDR6 frame buffer on a 384-bit memory bus. This is not a gaming card rebranded for workstations: it is designed from the ground up for compute-intensive professional workflows including AI-assisted video analytics, large-scene forensic image rendering, multi-stream 8K visualization, and real-time 3D modeling. If your deployment stack demands a GPU that can sustain heavy encode/decode, drive four simultaneous 8K DisplayPort outputs, and feed a machine learning inference pipeline without page-fault thrashing, the 79C23AA is the card to evaluate.

Key Features

• 18,176 CUDA Cores (Ada Lovelace Architecture): The RTX 6000 Ada's sheer core count means parallel compute workloads — AI inference, video transcoding, physics simulation — execute without the bottlenecks you hit on mid-range cards. For environments running GPU-accelerated video analytics across dozens of concurrent streams, this is a meaningful headroom spec.
• 48GB GDDR6 Frame Buffer: This is the number that separates the RTX 6000 Ada from every consumer and prosumer GPU. 48GB means you can load large AI models, multi-resolution texture sets, or full-resolution multi-channel video streams entirely into VRAM without CPU-side offloads degrading throughput. Real-world impact: large surveillance scene rendering and deep learning inference pipelines stay in-card, not swapping to system RAM.
• 960 GB/s Memory Bandwidth via 384-bit Bus: The combination of a wide 384-bit bus and GDDR6 delivers 960 GB/s peak bandwidth — roughly twice what a 256-bit consumer card achieves. That bandwidth headroom prevents GPU memory starvation during burst compute phases, which matters when you're processing multiple uncompressed 4K or 8K feeds simultaneously.
• Four DisplayPort 1.4a Outputs (8K @ 7680×4320): The 79C23AA drives up to four displays at a maximum resolution of 7680×4320 each. For physical security operations centers running large video walls or multi-monitor analyst workstations, this eliminates the need for secondary display adapters — one card handles the entire display array.
• PCIe 4.0 x16 Interface: PCIe Gen 4 doubles the host interface bandwidth over Gen 3. On workstations processing high-resolution video streams from NVR storage to the GPU for analytics, the added bus bandwidth reduces CPU-to-GPU transfer latency. Verify that your host system supports PCIe 4.0 to realize the full benefit.
• DirectX 12.0 / OpenGL 4.6 / OpenCL 3.0 / Shader Model 6.6: Full support for current API versions means the card runs modern workstation applications without compatibility compromises. OpenCL 3.0 is relevant for GPU-accelerated VMS analytics engines that leverage OpenCL compute paths rather than CUDA-only pipelines.
• VR-Ready Certification: While many physical security deployments won't use VR, training simulation environments, digital twin walkthroughs of facility layouts, and immersive operator training platforms are increasingly common. The RTX 6000 Ada handles these without a separate GPU investment.
• HDCP Support: HDCP compliance means content-protected streams — relevant in broadcast, legal, and government workflows where HDCP-encrypted video sources must be rendered — can pass through without hardware decryption workarounds.

Integration and Compatibility

The 79C23AA installs into any PCIe x16 Gen 4 or Gen 3 slot (Gen 3 compatible, but bandwidth-limited). It is sourced as an HP SmartBuy unit, meaning it is factory-new and intended for HP workstation platforms — but the PCIe form factor is standard and compatible with non-HP workstations that meet power and physical clearance requirements. Verify power supply headroom before installing: the RTX 6000 Ada's TDP is not documented in the supplied evidence, so consult NVIDIA's RTX 6000 Ada specifications for PSU requirements before procurement. Four DisplayPort 1.4a outputs support daisy-chaining where monitors permit. No HDMI output is present on this configuration — if your display array requires HDMI, plan for active DP-to-HDMI adapters. The 79C23AA carries a country of origin of CN and a UNSPSC code of 43201401 (graphics/video adapters).

Frequently Asked Questions

Q: What GPU is inside the HP Inc 79C23AA?

A: The 79C23AA is built on the NVIDIA RTX 6000 Ada Generation GPU (Ada Lovelace architecture) with 18,176 CUDA cores and 48GB of GDDR6 memory on a 384-bit bus.

Q: How many monitors can the 79C23AA drive simultaneously?

A: The card has four DisplayPort 1.4a outputs, supporting up to four displays. Maximum resolution per output is 7680×4320 (8K). There is no HDMI output on this SKU.

Q: Is the 79C23AA compatible with non-HP workstations?

A: The card uses a standard PCIe x16 Gen 4 interface and should physically install in compatible non-HP workstations. However, it is marketed and sourced as an HP SmartBuy unit — verify power supply capacity and chassis clearance for your specific workstation before ordering.

Q: Does the 79C23AA support OpenCL for VMS analytics workloads?

A: Yes. The RTX 6000 Ada supports OpenCL 3.0, which is used by a number of GPU-accelerated video management and analytics engines as an alternative to CUDA-only compute paths.

Q: What is the memory bandwidth of the 79C23AA?

A: Maximum memory bandwidth is 960 GB/s, delivered via a 384-bit GDDR6 memory bus. This is substantially higher than most consumer or prosumer GPUs and helps prevent memory starvation under heavy parallel compute loads.

Q: Is the 79C23AA VR-ready?

A: Yes, the RTX 6000 Ada is VR-ready, supporting virtual reality applications and immersive visualization platforms in addition to standard multi-display workstation workflows.

Ted Perry

The spec that defines whether the 79C23AA belongs in your deployment is the 48GB GDDR6 frame buffer — not the CUDA core count, not the clock speeds. When you're running a physical security operations center with GPU-accelerated AI analytics across 32+ camera streams, or ingesting uncompressed 4K footage for forensic review alongside a live inference model, you hit VRAM limits on 16GB and 24GB cards well before you hit compute limits. The RTX 6000 Ada on the 79C23AA eliminates that wall entirely.

Technical Highlights:

• 48GB GDDR6 / 384-bit bus: At 960 GB/s bandwidth, the memory subsystem sustains throughput even when multiple parallel compute threads are competing for bus access — critical in multi-stream AI decode pipelines where burst memory demand is unpredictable.
• 18,176 CUDA Cores: Sufficient to run large deep learning inference models (object detection, behavioral analytics, license plate recognition) concurrently without time-slicing that would introduce latency in real-time monitoring contexts.
• Four DisplayPort 1.4a at 7680×4320: A four-head 8K configuration from a single card means a four-display 4K video wall or analyst workstation requires no secondary GPU — simplifying driver management, reducing PCIe slot consumption, and eliminating multi-GPU sync issues.

Deployment Considerations:

• The PCIe 4.0 x16 interface delivers its full bandwidth benefit only on Gen 4-capable host platforms — if your workstation is Gen 3, the card still operates but at reduced host-to-GPU transfer speeds. For pure GPU compute (inference, rendering) rather than host-to-GPU streaming, the practical impact is minimal.
• No HDMI output is present on the 79C23AA — plan for active DisplayPort-to-HDMI adapters if any displays in your ops center array are HDMI-only. Passive adapters may not carry full 8K signal at the required refresh rate.

The 79C23AA is the right call for a centralized AI analytics workstation in a large-campus physical security deployment — specifically where a single server-class workstation is aggregating GPU inference for 50+ camera feeds, or where a forensic review workstation needs to render full-resolution 8K evidence footage across a four-monitor array without a separate compute node.
