Type:
Dome
Features:
AI
Features:
IR
Frame Rate:
30 fps
Sensor Type:
Two sensors, 1/1.8" Progressive Scan CMOS
Max. Resolution:
2560 × 1440
Min. Illumination:
0.0004 Lux color / 0 Lux IR
Shutter Speed:
1/1 s to 1/30000 s
Zoom:
35 × optical,16 × digital
Slow Shutter:
Yes
BLC:
yes
3D DNR:
yes
Focal Length:
5.9 to 206.5 mm
Field of View:
60.2° to 2.24° horizontal
Focus:
Auto,semi-auto,manual
Aperture:
Max. F1.6
Zoom Speed:
Approx. 4.3 s
Supplement Light Type:
Hybrid
Supplement Light Range:
IR distance: up to 300 m
Smart Supplement Light:
Yes
Movement Range (Pan:
360° endless
Movement Range (Tilt:
-20° to 90°,auto flip
Pan Speed:
Configurable 0.1–210°/s, preset 280°/s
Tilt Speed:
0.1–150°/s (configurable), 250°/s preset
Proportional Pan:
Yes
Presets:
300
Preset Freezing:
Yes
Patrol Scan:
8 patrols, up to 32 presets for each patrol
Pattern Scan:
4 pattern scans, record time over 10 minutes for each scan
Park Action:
Preset, Pattern, Patrol, Auto, Tilt, Random, Frame, Panorama
3D Positioning:
Yes
PTZ Status Display:
Yes
Scheduled Task:
Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,dome reboot,dome adjust,aux output,panorama scan
Power-Off Memory:
Yes
Main Stream:
2560×1440 @ 25fps
Sub-Stream:
704×576 @ 25fps
Third Stream:
1920×1080 @ 25fps
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264, +more
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline profile,Main profile,High profile
H.265 Type:
Main profile
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
8 fixed regions for each stream
Audio Compression:
G.711,G.722.1,G.726,MP2L2,PCM,AAC-LC
Audio Bit Rate:
64 Kbps (G.711), 16 Kbps (G.722.1), 16 Kbps (G.726), +more
Protocols:
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv4/IPv6,UDP,Bonjour
Simultaneous Live View:
Up to 20 channels
API:
ONVIF Profile S/G/T, ISAPI, SDK, ISUP
User/Host:
32 users, 3 levels
Security:
Password protection,complicated password,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),watermark,IP address filter,basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for Open Network Video Interface, R
Network Storage:
NAS (NFS, SMB/CIFS),auto network replenishment (ANR)
Client:
iVMS-4200,HikCentral Pro,Hik-Connect
Web Browser:
Safari12+,Chrome57+,Firefox52+,IE10+
Image Parameters Switch:
Yes
Image Settings:
Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Day/Night Switch:
Day,night,auto,schedule
Wide Dynamic Range (WDR:
140 dB
SNR:
≥ 52 dB
Defog:
Optical defog
Image Stabilization:
EIS (Built-in gyroscope to improve EIS performance)
Privacy Mask:
24 programmable polygon masks
Regional Focus:
Yes
Regional Exposure:
Yes
Satellite Positioning:
No
Gyroscope:
Yes
Compass:
No
Video Outputs:
CVBS: 1.0 V[p-p]/75 Ω, PAL/NTSC, BNC connector
Ethernet Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
On-Board Storage:
microSD/microSDHC/microSDXC, up to 256GB
Audio Support:
1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω
Alarm:
7 input(s), 2 output(s)
RS-485:
1x RS-485 Half Duplex
Reset:
Yes
Basic Event:
Motion detection,video tampering alarm,exception,alarm input and output
Smart Event:
Line crossing detection,intrusion detection,region entrance detection,region exiting detection,audio exception detection,unattended baggage detection,object removal detection
Linkage:
Upload to FTP/NAS/memory card, email, alarm
Smart Tracking:
Manual tracking,auto-tracking
Face Capture:
Face detection and tracking
Face Comparison:
Recognizes face identity via face modeling, grading and comparing to those in face library
Road Traffic:
Vehicle detection with plate/model/color recognition
Power Type:
36 VDC ± 25%, max. 62 W, Hi-PoE
Dimension:
Ø267 mm × 430 mm (Ø10.5" × 16.9")
Weight:
Approx. 10 kg (22.05 lb.)
Material:
ADC12
Operating Condition:
-40°C to 70°C, 95% RH non-condensing
Vandal-Proof Alarm:
Yes
Heater:
Yes
Wiper:
Yes
Demist:
Yes
Language:
33 languages: English, Russian, Estonian, Bulgarian, +more
EMC:
FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014),KC (KN 32: 2015, KN 35: 2015),RCM (AS/NZS CISPR 32: 2015),IC (ICES-003: Issue 7)
Safety:
UL (UL 62368-1),CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017),BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005),LOA (IEC/EN 60950-1)
Environment Rating:
CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No 1907/2006)
Protection:
IP67, IK10, 6kV surge protection
Product Type:
Dome
Connectivity:
Wired
Night Vision:
IR
Form Factor:
Dome
IP Rating:
IP67
Vandal Rating:
IK10
Max Channels:
20
Resolution:
4MP
Day/Night:
Yes
Optical Zoom:
35x
Analytics:
LPR
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Image Sensor Size:
1/1.8"
Horizontal Fov:
60.2°
Vertical Fov:
36°
Wide Dynamic Range:
WDR
Housing Color:
White
Warranty:
5-year warranty
