Image Sensor:
1/2.8" Progressive Scan CMOS
Max. Resolution:
1920 × 1080
Min. Illumination:
Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Shutter Time:
1/3 s to 1/100,000 s
Day & Night:
IR cut filter
Angle Adjustment:
Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°
Depth Of Field:
0.5 m to ∞
Focal Length & FOV:
2.8 to 12 mm, horizontal FOV 107° to 32°, vertical FOV 55° to 18°, diagonal FOV 130° to 36°
Aperture:
F1.6
Lens Mount:
Ø14
Lens Type:
Varifocal lens, motorized lens, 2.8 to 12 mm
Iris Type:
Fixed
DORI:
2.8 to 12 mm: Wide: D: 45.5m, O: 18.1m, R: 9.1m, I: 4.6m;Tele: D: 137.9m, O: 54.7m, R: 27.6m, I: 13.8m
IR Wavelength:
850 nm
Supplement Light Type:
IR
Supplement Light Range:
Up to 40 m
Smart Supplement Light:
Yes
Main Stream:
50 Hz: 25 fps (1920 × 1080, 1280 × 720);60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (640 × 480, 640 × 360);60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream:
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360);60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Video Compression:
Main stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264
Video Bit Rate:
32 Kbps to 8 Mbps
H.264 Type:
Baseline Profile,Main Profile,High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR,VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
1 fixed region(s) for main stream and sub-stream
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate:
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Simultaneous Live View:
Up to 6 channels
API:
Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
User/Host:
Up to 32 users;3 user levels: administrator, operator, and user
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Inter
Network Storage:
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)
Client:
iVMS-4200,Hik-Connect,Hik-Central
Web Browser:
Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Local service: Chrome 57.0+, Firefox 52.0+
Privacy Mask:
Yes
Day/Night Switch:
Day,Night,Auto,Schedule
Image Enhancement:
BLC,HLC,3D DNR
Image Parameters Switch:
Yes
Image Settings:
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Wide Dynamic Range (WDR:
120 dB
SNR:
≥ 52 dB
Audio:
1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type
Alarm:
1 input(s), 1 output(s) (max. 24 VDC/24 VAC, 1 A)
On-Board Storage:
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Reset Key:
Yes
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
Basic Event:
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Smart Event:
Line crossing detection, intrusion detection(support alarm triggering by specified target types (human and vehicle)), face detection
Linkage:
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning
Power:
12 VDC ± 25%, 0.88 A, max. 10.5 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: 802.3 af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W
General Function:
Heartbeat,anti-flicker,password reset via email,pixel counter
Storage Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Material:
Upper cover and base: metal, bubble: plastic
Dimension:
Ø153.3 mm × 111.6 mm (Ø6.1 × 4.4\")"
Package Dimension:
244 mm × 174 mm × 173 mm (9.7" × 6.9" × 6.9")
Weight:
Approx. 880 g (1.9 lb.)
With Package Weight:
Approx. 1460 g (3.1 lb.)
Language:
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Tradition
EMC:
FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
Safety:
UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017
Environment:
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
Protection:
IP67: IEC 60529-2013;IK10: IEC 62262:2002
