Type:
Bullet
Features:
AI
Frame Rate:
High
Sensor Type:
1/3" Progressive Scan CMOS
Max. Resolution:
2560 × 1440
Min. Illumination:
0.005 Lux color / 0 Lux IR
Shutter Time:
1/3 s to 1/100,000 s
Day & Night:
IR cut filter
Angle Adjustment:
Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
Lens Type:
Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV:
2.8mm (98° H) / 4mm (78° H)
Lens Mount:
M12
Iris Type:
Fixed
Aperture:
F1.6
DORI:
2.8mm@63m, 4mm@78m
Supplement Light Type:
IR,White Light
Supplement Light Range:
Up to 30 m
Smart Supplement Light:
Yes
IR Wavelength:
850 nm
Main Stream:
2560×1440 @ 20fps
Sub-Stream:
1280×720 @ 25fps
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264, +more
Video Bit Rate:
32 Kbps to 8 Mbps
H.264 Type:
Baseline Profile,Main Profile,High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR,VBR
Region Of Interest (ROI:
1 fixed region for main stream
Audio Type:
Mono sound
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8 kHz/16 kHz
Audio Compression:
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
Audio Bit Rate:
64 Kbps (G.711), 16-32 Kbps (G.722.1/G.726), 32-160 Kb
Security:
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
Simultaneous Live View:
Up to 6 channels
API:
Open Network Video Interface, ISAPI, SDK
Protocols:
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
User/Host:
32 users; 3 levels
Client:
iVMS-4200,Hik-Connect
Web Browser:
Plug-in required live view: IE 10, IE 11, +more
Wide Dynamic Range (WDR:
120 dB
SNR:
≥ 52 dB
Day/Night Switch:
Day,Night,Auto,Schedule
Image Enhancement:
BLC,HLC,3D DNR
Image Settings:
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Privacy Mask:
4 programmable polygon privacy masks
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:
microSD/microSDHC/microSDXC, up to 512GB
Built-In Microphone:
Yes
Reset Key:
-F: Yes
Basic Event:
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Linkage:
FTP upload, email, notification, recording, capture
Power Type:
PoE
Material:
Metal & Plastic
Dimension:
170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7")
Package Dimension:
216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
Weight:
Approx. 270 g (0.6 lb.)
With Package Weight:
Approx. 481 g (1.1 lb.)
Storage Conditions:
-30°C to 60°C, 95% RH non-condensing
Startup And Operating Conditions:
-30°C to 60°C
Language:
English, Ukrainian
General Function:
Heartbeat,anti-banding,mirror,password protection,password reset via email
EMC:
FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7
Safety:
UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
Environment Rating:
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
Protection:
IP67: IEC 60529-2013
Product Type:
Bullet
Connectivity:
Wired
IP Rating:
IP67
Night Vision:
IR
PoE Class:
3
Form Factor:
Bullet
Max Channels:
6
Resolution:
4MP
Audio Support:
Yes
Day/Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
WDR:
WDR
Image Sensor Size:
1/3"
Horizontal Fov:
98°
Vertical Fov:
54°
Wide Dynamic Range:
WDR
Housing Color:
White
Warranty:
5-year warranty
