HES AM6340 Maglock Mounting Brackets
The AM6340 maglock brackets are mechanical mounting components designed to secure electromagnetic lock units to standard door frames and flat wall surfaces in professional access control installations. These brackets bridge the gap between maglock hardware and architectural surfaces, eliminating the guesswork around mounting orientation, alignment, and load distribution.
Key Features
- Door Frame and Wall Mounting: Bracket geometry accommodates both vertical door frame installation (the most common retrofit scenario) and direct wall surface mounting, reducing the need for custom fabrication or workarounds in non-standard openings.
- Compatible with HES Electromagnetic Lock Systems: Engineered specifically for HES electromagnetic lock units, ensuring mechanical fit and load rating alignment. Swapping brackets across brands risks misalignment and premature wear.
- Includes Mounting Hardware: Ship complete with fasteners and anchors appropriate for standard drywall, masonry, and frame construction — no separate ordering of hardware packs or hunting for compatible bolts.
- Indoor Access Control Environments: Optimized for interior deployment in office buildings, educational facilities, healthcare properties, and commercial spaces where weathering is not a concern.
- Standard Installation Footprint: The bracket form factor aligns with common access control installation templates, reducing field measurement time and commissioning complexity on larger multi-door deployments.
Integration and Compatibility
The AM6340 brackets are purpose-built for HES maglock systems and will not work with electromagnetic locks from other manufacturers without field modification. If you are replacing an existing maglock system, confirm that the legacy and new lock units share the same bracket mounting pattern — do not assume. The brackets themselves do not contain electronic components, so they carry no firmware, configuration, or cybersecurity considerations; they are passive mechanical hardware.
Deployment Scenarios
Use the AM6340 for retrofit installations in existing door frames where architectural access is straightforward (e.g., single-leaf office doors, institutional secure entrances). The bracket is also appropriate for new construction where door frame dimensions are known in advance. If your opening requires custom welding, embedded anchors in concrete, or specialized framing (e.g., glass partition mounting), plan to supplement the standard AM6340 with on-site fabrication or consult with your systems integrator before committing to this model.
Installation Notes
Proper bracket alignment directly affects maglock durability and door closure reliability. Misalignment — even 1/8 inch — can cause binding on the strike plate and accelerate wear on both the lock and door hardware. Use a level during installation and verify that the bracket sits flush against the frame or wall surface before tightening final fasteners. If the door frame is warped or the wall surface is uneven, shim the bracket to achieve flush contact rather than forcing it into place.
Frequently Asked Questions
Q: Can I use the AM6340 on an outswinging door?
A: The bracket mounting orientation determines door swing direction compatibility. Verify your door swing (inswing vs. outswing) before installation; some bracket orientations are optimized for one direction.
Q: Are the AM6340 brackets weather-resistant?
A: No. The AM6340 is rated for indoor environments only. Exterior applications require brackets with stainless steel construction and sealed fasteners — consider a manufacturer's outdoor-rated variant if your deployment includes exposed-to-weather door frames.
Q: What wall surface types can the AM6340 brackets mount to?
A: Standard drywall (with appropriate anchors), wood studs, and masonry (with masonry fasteners). If mounting to glass partitions or composite materials, field engineering may be required.
Q: Does the AM6340 include installation documentation?
A: The bracket ships with mounting hardware and a basic installation guide. Detailed template drawings and frame-specific guidance should be obtained from the manufacturer or your integrator before beginning installation.
Q: Can the AM6340 be retrofitted to replace brackets from another manufacturer?
A: Only if the legacy bracket mounting holes and strike-plate geometry match the AM6340 exactly. Do not assume cross-compatibility — measure and compare drawings first.
Jerry TildsenPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The AM6340 is a straightforward accessory, but that simplicity masks a critical decision point: bracket quality and fitment directly affect lock performance and door reliability. Poor mounting alignment causes strike-plate binding, lock wear, and eventual access denial — exactly the failure mode you cannot troubleshoot remotely. The AM6340's inclusion of matched fasteners and frame-compatible geometry eliminates the most common field installation errors.
Key Installation Considerations:
- Mounting Surface Alignment: The bracket must sit flush to the frame or wall. Warped frames or uneven surfaces demand shimming before final fastening — do not force the bracket flat against a non-planar surface, as this creates uneven load distribution and accelerates lock mechanism wear.
- Hardware Completeness: The AM6340 arrives with all fasteners needed for standard drywall, wood, and light masonry substrates. If your installation involves solid concrete, composite door frames, or glass partition mounting, verify that the hardware pack includes appropriate anchors before site arrival.
- Inswing vs. Outswing Verification: Bracket orientation is not field-reversible. Confirm door swing direction before installation; reversing a bracket after final tightening requires complete removal and re-drilling of anchor holes.
When to Use the AM6340: This bracket is the right choice for interior retrofit or new-construction deployments on standard door frames (wood or metal studs, drywall backing) where the opening is accessible and frame geometry is known. If you are integrating into a complex renovation, a facade with embedded anchors, or an exterior application, engage your mechanical designer to confirm that the AM6340 will not require field modification — the cost of retrofit welding or custom fabrication often exceeds the budget saved by choosing the standard bracket.
