Hanwha XNB-8003 6MP AI Box IP Camera

Hanwha XNB-8003 6MP AI Day/Night Extreme WDR Outdoor Box IP Camera

The Hanwha XNB-8003 is a professional-grade 6MP box network camera engineered for demanding surveillance environments. Built on a 1/1.8" progressive CMOS sensor, this camera delivers exceptional image clarity at resolutions up to 3328x1872 at 30fps, making it ideal for applications requiring high-resolution detail capture. The XNB-8003 combines advanced imaging technologies with AI-powered analytics to provide both comprehensive video monitoring and actionable security intelligence.

Key Features

• Extreme Wide Dynamic Range (120dB): Captures fine details in high-contrast scenes with simultaneous bright and dark areas
• AI Engine with Advanced Analytics: Real-time object detection for persons, faces, vehicles, and license plates; virtual line crossing and area entry/exit detection
• Superior Low-Light Performance: 0.03 Lux color sensitivity and 0.003 Lux black & white, with selectable day/night operation
• Multiple Compression Formats: H.265, H.264, and MJPEG support for flexible bandwidth optimization
• Intelligent Video Optimization: WiseStream III and WiseNR II (AI-based) reduce noise while maintaining critical detail
• Edge Storage: Dual microSD/SDHC/SDXC slots supporting up to 1TB local recording capacity
• Built-in Stabilization: Digital image stabilization with integrated gyro sensor for smooth footage
• PoE Powered: IEEE 802.3af Class 3 compatibility with minimal power draw (typical 9.8W PoE)

Technical Highlights

The XNB-8003 features flexible lens options with C-mount and CS-mount compatibility, supporting manual, DC auto-iris, P-iris, and I-CS control for precise aperture management. Video rotation capabilities include flip, mirror, and 90°/270° hallway view modes. The camera includes 8 polygonal motion detection zones and 32 privacy masking areas (quad or mosaic), plus 2 configurable I/O ports for alarm integration.

For connectivity, the camera supports ONVIF Profile S/G/T/M, SUNAPI HTTP API, and Wisenet open platform integration. Security is enforced through TPM 2.0 (FIPS 140-2 level 2), HTTPS/SSL, IP filtering, 802.1X authentication, and user access logging. Supported protocols include IPv4/IPv6, RTSP, RTCP, DHCP, DDNS, QoS, and MQTT for flexible network deployment.

Audio capabilities include selectable mic-in, line-in, or built-in microphone with G.711/G.726 compression, plus line-out for two-way communication. The camera operates reliably from -10°C to +55°C with 0-95% humidity tolerance.

Applications

The XNB-8003 excels in high-security perimeter monitoring, traffic enforcement, retail loss prevention, and facility access control. Its AI analytics enable people counting, queue management, and heatmap visualization for operational insights beyond traditional surveillance.

Marty Allison

The XNB-8003 represents Hanwha's commitment to AI-integrated surveillance at the edge. The 120dB extreme WDR combined with intelligent noise reduction makes this camera particularly valuable for mixed-lighting outdoor installations where detail preservation is critical. The dual microSD slot and edge storage capability provide resilience against network disruptions, while ONVIF compliance ensures vendor flexibility.

Organizations prioritizing analytics-driven security and operational intelligence will find the built-in person/vehicle/license plate detection and business intelligence features (people counting, heatmap) eliminate the need for expensive VMS plug-ins. The PoE Class 3 power envelope and compact 81×67×165mm form factor simplify integration into existing infrastructure. Consider this camera for deployments where real-time analytics ROI justifies the advanced sensor investment.
