Hanwha WRR-P-S204S Wave Recording Server

Hanwha WRR-P-S204S Wave Recording Server

The Hanwha WRR-P-S204S is a professional-grade 2U network video recording server designed for large-scale surveillance deployments. Built on the Hanwha Wave VMS platform, this robust recorder combines enterprise-class hardware with flexible storage architecture to support mission-critical security operations. With support for up to 240TB raw storage capacity and 470 Mbps recording bandwidth, the WRR-P-S204S delivers the performance and scalability required by organizations managing extensive camera networks.

Key Features

• Hanwha Wave VMS with 4 Professional licenses pre-installed
• Up to 470 Mbps recording bandwidth for high-volume video ingestion
• Maximum 240TB raw storage (200TB usable with RAID 5 configuration)
• 12 x 3.5" front hot-swappable drive bays with flexible RAID support
• Dual 480GB SSD OS drives in RAID 1 configuration for system reliability
• Intel Xeon 4410Y processor with 16GB DDR4 RAM
• Redundant 800W 80 Plus Platinum power supplies for continuous operation
• Multiple video outputs: NVIDIA Quadro T400 GPU with 3 x MiniDisplayPort, 2 x VGA
• 4 x 1GbE NICs (expandable to 2 x 1GbE + 2 x 10GbE SFP)
• Windows Server 2022 Standard, Windows 10 IoT Enterprise LTSC 2021, or Ubuntu 22.04 LTS support
• Keyboard, mouse, and sliding rail kit with cable management arm included

Technical Specifications

Storage & Performance: The server supports RAID 0, 1, 5, 6, and 10 configurations with RAID 5 as the default. The dual SSD boot drives ensure rapid system initialization and consistent performance. With 12 hot-swappable bays, storage expansion and maintenance can be performed without system shutdown.

Network Connectivity: Standard configuration includes 4 x RJ45 Gigabit Ethernet ports. Organizations requiring higher throughput can opt for 2 x 1GbE plus 2 x 10GbE SFP connectivity, enabling multi-camera stream aggregation and redundant network paths.

Compute Power: The Intel Xeon 4410Y processor and 16GB RAM support the Wave VMS software and concurrent video streams with minimal latency. NVIDIA Quadro T400 graphics acceleration enables responsive display performance and multi-monitor support.

Environmental Compliance: The WRR-P-S204S meets UL, NOM, RoHS, TUV, and GS certifications. Operating temperature range of 50–95°F (10–35°C) supports deployment in controlled data center environments.

Applications

• Large-scale enterprise surveillance systems
• Multi-site security operations centers
• Critical infrastructure monitoring
• Retail and logistics facilities with extensive camera networks
• Government and institutional deployments

Karl Wilson

The WRR-P-S204S represents Hanwha's commitment to scalable, enterprise-grade video recording. Its 12-bay architecture and 240TB capacity address organizations that require long-term retention without external storage complexity. The inclusion of 4 Wave Professional licenses provides immediate software investment value.

Redundant power supplies and RAID flexibility ensure high availability—critical for security-sensitive environments. The optional 10GbE networking upgrade supports bandwidth-intensive deployments, while the flexible OS support (Windows Server, IoT Enterprise, Ubuntu) accommodates diverse IT environments. This is a production-ready appliance for organizations prioritizing reliability and operational simplicity over external storage dependencies.
