Hanwha TNS-9050IBC 4K Thermal Barcode Reader Camera
The Hanwha TNS-9050IBC is a high-performance 4K thermal barcode reader camera engineered for industrial automation, logistics, and quality control applications. This dual-sensor system combines monochrome and color 4K imaging to deliver simultaneous barcode recognition and video surveillance from a single integrated device. With intelligent WiseBCR analytics pre-installed, the TNS-9050IBC automates barcode capture and tracking on high-speed production lines while maintaining full video monitoring capabilities.
Key Features
- Dual 4K sensors (monochrome and color) operating at 20fps per sensor
- 25mm machine vision lens for precision barcode capture and wide field of view
- WiseBCR application supporting 1D/2D barcode recognition: Code128, Codabar, Interleaved 2 of 5
- Removable and replaceable 32-LED illumination module for flexible lighting control
- IP67 (water and dust protection) and IK10 (impact resistance) ratings
- Operating temperature range: -40°C to +55°C for extreme environments
- M12 8-pin Ethernet connectivity for seamless integration
- 24VDC power supply simplifies installation
- EN 60068-2-6 vibration and EN 60068-2-27 shock resistance compliance
Technical Highlights
Built for demanding industrial environments, the TNS-9050IBC features ruggedized construction with IP67 and IK10 ratings, ensuring reliable operation in harsh conditions including moisture, dust, and mechanical shock. The dual 4K sensor architecture enables simultaneous high-resolution barcode reading and color video monitoring without performance compromise. The preinstalled WiseBCR application provides real-time barcode recognition across common 1D and 2D formats, making it ideal for conveyor belt systems operating at speeds up to 2 meters per second.
The removable 32-LED module delivers optimized illumination for barcode surfaces, with easy field replacement reducing downtime during maintenance. M12 8-pin Ethernet connectivity ensures compatibility with industrial network infrastructure, while 24VDC power integration simplifies deployment in existing automation systems. Extended operating temperature range of -40°C to +55°C qualifies this camera for both heated indoor facilities and uncontrolled outdoor or cold storage environments.
Applications
- Parcel and package sorting in logistics facilities
- Pharmaceutical and manufacturing quality control
- Conveyor belt barcode verification and tracking
- Warehouse inventory management and automated picking
- High-speed production line authentication
Karl WilsonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The TNS-9050IBC addresses a critical gap in industrial automation: the need for simultaneous high-resolution barcode reading and video documentation. The dual 4K sensor approach eliminates the compromise between barcode recognition accuracy and situational video awareness. The WiseBCR application's support for multiple 1D/2D formats ensures compatibility with diverse barcode ecosystems across manufacturing and logistics sectors.
The removable LED module is a practical design choice that reduces total cost of ownership by enabling in-field maintenance without device replacement. For integrators, the M12 Ethernet connection and 24VDC power requirement provide straightforward system integration, while IP67/IK10 ratings and extended temperature range justify deployment in non-climate-controlled facilities.
