Hanwha TNO-P9072EPT1-Z 8MP Explosion Proof Fixed Camera

Hanwha TNO-P9072EPT1-Z 8MP Explosion Proof Fixed Camera

The Hanwha TNO-P9072EPT1-Z is a robust 8-megapixel explosion-proof fixed IP camera engineered for hazardous environments requiring both high-resolution imaging and certified safety compliance. Rated for Class I, II, and III Division 1 locations and cFMus/ATEX/IECEX certified, this camera delivers professional-grade surveillance in petrochemical facilities, refineries, mining operations, and other explosive atmospheres where standard cameras cannot operate.

Key Features

• 8MP 1/1.8" CMOS sensor with 4K resolution (3840 x 2160) at 30fps
• 3.9-10mm f1.5 varifocal i-CS lens with remote and manual focus control
• True Day & Night with automatic ICR switching, defog, and 120dB wide dynamic range
• Advanced AI-powered video analytics: object detection, face mask detection, directional detection, digital auto tracking, loitering, and virtual line crossing
• Explosion-proof housing: powder-coated aluminum, IP66-rated, NEMA 4X compliant
• Dual SD/SDHC/SDXC card slots supporting up to 512GB local edge storage
• PoE+ powered with low 25.5W maximum consumption
• Multiple codec support: H.265, H.264, and MJPEG with WiseStream II bitrate optimization
• Bi-directional audio communication with selectable microphone/line inputs
• RS-485 control supporting industry-standard protocols (Pelco-P/D, Samsung-T/E, and others)

Technical Highlights

The camera's 1/1.8" 8MP imaging sensor captures 3,864 x 2,180 total pixels with exceptional low-light performance at 0.03 Lux (color) and 0.003 Lux (B&W). Built-in gyro-based digital image stabilization compensates for vibration common in industrial environments. The varifocal lens provides flexible field-of-view adjustment from 3.9-10mm without requiring physical lens changes.

Advanced image processing includes lens distortion correction (5 levels), 2D+3D noise filtering, and electronic shutter speeds from 2 to 1/12,000 seconds with anti-flicker modes. The 24x digital PTZ with AI-assisted auto-tracking enables intelligent object follow-up across scenes. Eight configurable motion detection zones and six privacy masking areas support custom deployment requirements.

Enterprise Integration

Supporting up to 10 simultaneous streaming profiles, the TNO-P9072EPT1-Z accommodates 20 concurrent unicast users. ONVIF Profile S/G, Wisenet Open Platform, and RESTful HTTP APIs enable seamless integration with third-party VMS platforms. IPv4/IPv6 networking includes HTTPS/SSL encryption, 802.1X authentication, and IP filtering for secure deployments. Alarm I/O (1 input/output pair) triggers FTP uploads, email notifications, and NAS recordings on event detection.

Applications

Ideal for hazardous area surveillance including: petrochemical and oil & gas facilities, chemical processing plants, mining operations, explosive manufacturing environments, and other Class I, II, or III Division 1 locations. The combination of high resolution, intelligent analytics, and certified explosion-proof design makes this camera essential for compliance-critical industrial security.

Karl Wilson

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The TNO-P9072EPT1-Z represents a significant advancement in hazardous-area surveillance by combining enterprise-grade imaging capabilities with rigorous explosion-proof certification. The 8MP 4K resolution and advanced AI analytics distinguish this from legacy explosion-proof cameras, enabling proactive monitoring such as unauthorized loitering or perimeter breach detection in critical infrastructure.

The dual SD card architecture with continuous failover recording provides edge redundancy, critical for facilities where network outages cannot compromise security. PoE+ powered operation simplifies deployment by eliminating separate power runs to hazardous-area junction boxes. Support for industry-standard protocols (Pelco, Samsung, Honeywell) ensures compatibility with existing industrial control systems. The IP66 rating and powder-coated aluminum construction withstand corrosive offshore and chemical processing environments. For organizations balancing regulatory compliance with operational intelligence requirements, this camera delivers both without compromise.
