Hanwha TNO-3010T QVGA Thermal Bullet IP Camera

Hanwha TNO-3010T QVGA Thermal Bullet IP Camera

The Hanwha TNO-3010T is a compact QVGA thermal bullet camera engineered for perimeter security, industrial monitoring, and round-the-clock surveillance in total darkness. Built on an uncooled micro bolometer sensor with 320×240 resolution and exceptional thermal sensitivity of less than 60mK, this camera delivers reliable heat signature detection for intrusion detection, fire prevention, and temperature anomaly identification across demanding outdoor environments.

Key Features

• QVGA thermal imaging (320×240) with uncooled micro bolometer sensor
• Thermal sensitivity (NETD) <60mK for precise heat detection
• 30fps video at all resolutions via H.265, H.264, and MJPEG codecs
• WiseStream II smart codec technology for optimized bandwidth
• Eight selectable color palettes: Whitehot, Blackhot, Rainbow, Sepia, Iron, Red, and Custom modes
• Built-in gyro sensor for digital image stabilization
• Advanced analytics: motion detection, directional detection, loitering, tampering, virtual line, audio detection, and temperature change detection
• 2.7mm fixed focal lens with 92° horizontal field of view
• IP66, IK10, NEMA4X certified for harsh outdoor conditions
• Operating temperature range -40°C to +60°C (-40°F to +140°F)

Technical Highlights

The TNO-3010T combines thermal detection with intelligent video analytics to automate security workflows. Eight configurable motion detection zones with 8-point polygonal masking enable precise area monitoring, while 32 privacy masking zones in multiple colors support regulatory compliance. The camera supports up to 20 unicast and multicast streaming profiles simultaneously, making it ideal for multi-site deployment.

Audio capabilities include selectable microphone or line-in input with dual compression formats (G.711, G.726, AAC-LC), plus 2-way audio output. Two alarm outputs and one alarm input support direct integration with access control and notification systems. Edge storage via microSD/SDHC/SDXC (up to 256GB) enables autonomous recording, while FTP and email event triggers provide real-time alerting.

Network flexibility includes three power options: PoE (IEEE 802.3af), 24VAC, or 12VDC input, with typical power consumption as low as 6.7W on 12VDC. The camera runs at 1GB RAM and 256MB Flash, supporting IPv4/IPv6, ONVIF Profile S/G/T, SUNAPI, and Wisenet open platform integration for seamless enterprise deployment.

Applications

• Perimeter intrusion detection and border security
• Industrial facility monitoring and equipment temperature surveillance
• Nighttime vehicle tracking and facility patrol verification
• Fire and hotspot detection in storage or manufacturing areas
• Wildlife and environmental monitoring
• Critical infrastructure protection (power, utilities, telecommunications)

Karl Wilson

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The TNO-3010T fills a critical role in all-weather, zero-light security by eliminating dependency on visible light and infrared illumination. Its sub-60mK thermal sensitivity means it can detect temperature differences of less than one-tenth of a degree, making it exceptionally capable for both intrusion detection and predictive maintenance use cases. The combination of H.265 compression, WiseStream II, and multiple codec support ensures efficient storage without sacrificing frame rate—a rare advantage in thermal imaging at this price tier.

IP66 and IK10 ratings confirm durability against salt spray, dust, and impact in harshest climates. Integrators should note the 2.7mm fixed lens provides broad 92° coverage ideal for perimeter mounting, though the QVGA resolution suits mid-to-far range detection rather than facial recognition. The built-in gyro stabilization is valuable for vibration-prone installations such as bridge-mounted or vehicular applications.
