Hanwha SBP-900CMW 900mm Pendant Ceiling Mount
The SBP-900CMW is an aluminum pendant mount engineered for flexible, discreet camera positioning in commercial and industrial ceiling installations. A 900mm extension length places cameras at optimal coverage angles without cluttering the visual field—critical in retail, warehouses, and office environments where aesthetics matter alongside security. The mount's clean geometry and white finish (RAL9003) integrate into most ceiling grids without drawing attention.
Key Features
- 900mm pendant extension: Extends your camera away from the ceiling plane, enabling sightlines that would otherwise be blocked by ductwork, beams, or ceiling structures. A 900mm drop is long enough to clear most obstructions without requiring additional pipe extensions, though the mount accepts extension accessories if you need more reach.
- Aluminum construction with white finish: Durable aluminum body resists corrosion and handles standard commercial environments. The RAL9003 white powder-coat finish blends into drop ceilings and painted surfaces, keeping the installation inconspicuous.
- TR30 mount screw interface: Connects directly to Hanwha hanging adaptors (SBP-120HMW, SBP-140HMW, SBP-160HMW1, SBP-180HMW1, and others). The standardized TR30 thread ensures compatibility across the Hanwha mount ecosystem without proprietary adapters.
- M25 threaded conduit opening (19.1mm / 3/4"): Accepts standard electrical conduit for organized, protected cable routing. Cables run inside the pendant itself, eliminating unsightly external runs and reducing accidental damage or tampering risk.
- Lightweight at 2.7kg (5.93 lbs): Minimal weight reduces ceiling anchor load, allowing installation into standard T-bar or gypsum ceiling grid without reinforcement. One technician can position and secure it without specialized rigging.
- Compatible with extension and adaptor accessories: Mix and match Hanwha's SBP-C15P, SBP-150CMP, SBP-300CMP, and SBP-900CMP extensions to customize drop length for specific deployment needs. The modular design accommodates future relocations or coverage adjustments without replacing the entire mount.
Integration & Compatibility
The SBP-900CMW (often searched as SBP 900CMW) pairs with any ceiling mount adaptor that uses the TR30 thread standard. Verified compatible adaptors include the SBP-120HMW (compact repositioning), SBP-140HMW, and SBP-160HMW1 series. Hanwha IP cameras with standard mount interfaces attach directly to these adaptors. If ceiling anchors are inadequate for your structure, consult a structural engineer—anchor load capacity is site-dependent, not a function of the mount itself.
Dimensions & Physical Specs
- Overall dimensions: ø180 × 958.5mm (ø7.09" × 37.63")
- Weight: 2.7kg (5.93 lbs)
- Material: Aluminum
- Color: White (RAL9003)
- Conduit opening: M25 threaded, 19.1mm (3/4")
When to Choose a Different Model
If you need a shorter drop, consider the SBP-150CMP or SBP-300CMP extension series—both accept the same adaptors and reduce pendant length for lower ceilings or tight overhead clearance. If your environment requires stainless steel for corrosive or washdown conditions, check with Hanwha's industrial mount catalog for alternatives. For PTZ or heavy camera platforms exceeding typical fixed-camera weight, verify anchor capacity with your structural documentation first.
Frequently Asked Questions
Q: What is the maximum camera weight the SBP-900CMW supports?
A: The mount itself is rated for standard fixed IP cameras (typically under 2 kg). Maximum load depends on your ceiling anchor type and installation—gypsum anchors, toggle bolts, and structural fasteners each have different limits. Consult your ceiling type and anchor specifications; Hanwha does not rate this mount for PTZ or heavy multi-sensor platforms.
Q: Can I use this mount indoors and outdoors?
A: The aluminum construction and white finish are suitable for standard indoor environments and covered outdoor areas (porches, covered parking). For fully exposed outdoor installations with direct rain or UV exposure, the aluminum and powder coat may degrade over time. If outdoor exposure is necessary, consider stainless steel alternatives from Hanwha's industrial line.
Q: Does the SBP-900CMW come with ceiling anchors?
A: No, this mount does not include anchors. Anchors depend on your ceiling type (drywall, concrete, drop-tile grid) and load requirements. Work with your installer to select appropriate anchors for your structure.
Q: What cable types fit through the M25 conduit opening?
A: The 19.1mm (3/4") opening accepts standard single or bundled network cables, power cables, and conduit sleeves. For dense multi-cable runs, you may need to route cables individually or use smaller-diameter conduit sleeves.
Q: Can I extend the SBP-900CMW if 900mm isn't enough?
A: Yes. The mount accepts additional extension accessories (SBP-C15P, SBP-150CMP, SBP-300CMP, SBP-900CMP) to increase total drop length. Add extensions below the pendant for cumulative reach. Verify total weight and ceiling anchor capacity for extended configurations.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The SBP-900CMW is a straightforward, well-engineered pendant mount that solves a real problem: getting your camera sightline clear of ceiling obstructions without breaking the visual plane. At 900mm extension, you're clearing most T-bar grids, ductwork, and sprinkler runs. The aluminum body is light enough that standard drywall anchors work on most installations, and the white finish doesn't scream 'security camera' the way black mounts do in retail or hospitality spaces.
Technical Highlights:
- 900mm pendant length: Places cameras 3 feet below the ceiling, positioning them to capture floor-level activity and faces without sightline obstruction. That's the critical spec—longer mounts exist, but 900mm covers most commercial ceiling heights and obstruction patterns.
- M25 threaded conduit pass-through: Runs cable inside the pendant, not outside. That protects it from accidental damage and keeps the visual installation clean. Standard 3/4" conduit sleeves slide through without modification.
- TR30 mount thread: Hanwha's standard for their adaptor line. It's not proprietary, but it's not universal either—you're locked into Hanwha's ecosystem. That's fine if you're already deploying their cameras, but verify adaptor compatibility before you install.
- 2.7 kg weight: Light enough that you don't need reinforced anchors on most gypsum or drop-tile ceilings. Your installer can position this solo without rigging hardware.
Deployment Considerations:
- Ceiling anchor capacity is YOUR responsibility, not Hanwha's. A light pendant on a poorly anchored ceiling is a falling object waiting to happen. Know your ceiling type and fastener rating before installation.
- The white finish is aluminum powder-coat, not stainless. In washdown environments (kitchens, food processing) or coastal salt-air, you're looking at oxidation over time. Indoor commercial and office spaces: no problem. Outdoor exposed: reconsider.
- The M25 conduit hole is threaded. It's designed for conduit, not just cable. If you're running loose cable, you'll want a strain relief or conduit adapter to prevent cable abrasion on the opening edges.
Deploy the SBP-900CMW in retail storefronts, office hallways, and warehouse aisles where you need cameras at face height without losing the visual clean look. It's a workhorse mount for spaces where aesthetics and sightline clarity both matter.
