Hanwha SBP-300PMW2 Pole Mount Base

Hanwha SBP-300PMW2 Pole Mount Base

The SBP-300PMW2 is a fixed pole mount base engineered for secure installation of Hanwha surveillance cameras and compatible accessories on standard structural supports. Built from corrosion-resistant aluminum with integrated cable management, this mount delivers reliable performance across commercial, industrial, and municipal surveillance deployments where pole-mounted fixed cameras are the standard approach.

Key Features

• Aluminum construction with white powder-coat finish (RAL9003): Corrosion resistance matters in outdoor and coastal environments where bare steel or untreated aluminum degrades quickly. The white finish also reflects solar heat, keeping camera and housing cooler during prolonged direct sunlight — a real factor when thermal drift affects image focus or sensor performance.
• M10 mount screw: Standardized attachment point compatible with Hanwha camera housings and compatible bracket systems. Provides secure mechanical interface without requiring custom adapters.
• M25 conduit hole: Pre-drilled cable management passage allows organized routing of power, network, and coaxial cables directly through the mount base, eliminating exposed cable runs that degrade appearance and invite tampering or accidental damage.
• Stainless steel mounting straps included: Two straps rated for poles with minimum 80mm diameter (roughly 3.15 inches). Stainless steel resists rust and corrosion where galvanized or painted steel straps would fail within 1–2 years in humid, salty, or chemically aggressive environments. No separate hardware ordering needed.
• Compact footprint: 185mm width × 115mm depth × 40mm height (7.28" × 4.53" × 1.57") keeps the overall profile low, reducing wind load and visual intrusion on poles shared with lighting, signs, or other utility infrastructure.
• Lightweight (750g / 1.65 lb): Minimal weight reduces pole stress and simplifies installation without climbing equipment or specialized rigging — particularly valuable for retrofit deployments on existing poles.

Integration & Compatibility

The SBP-300PMW2 pairs with TNO-7180RLP, SBP-300WMW, and SBP-300WMW1 products, forming a modular mounting ecosystem for pole-mounted surveillance configurations. M10 and M25 standardization ensures compatibility with the broader range of Hanwha IP cameras and protective housings used in fixed outdoor deployments. Cable routing through the M25 passage integrates cleanly with structured cabling practices, simplifying integration in network video recorder (NVR) installations where cable organization directly impacts maintenance and troubleshooting time.

What's in the Box

• 1x SBP-300PMW2 aluminum pole mount base (white, RAL9003)
• 2x stainless steel mounting straps for pole installation

Frequently Asked Questions

Q: What pole diameters does the SBP-300PMW2 support?

A: The stainless steel mounting straps accommodate poles with a minimum diameter of 80mm (approximately 3.15 inches). There is no maximum diameter specified in the design documentation; however, strap length becomes a practical constraint on very large structural members.

Q: Can I mount this directly to a wall instead of a pole?

A: The SBP-300PMW2 is engineered for pole installation using the included stainless steel straps. Wall mounting would require custom brackets and is not supported by the standard design.

Q: Does the M25 cable passage accommodate both power and network cables?

A: Yes. The M25 conduit hole allows simultaneous routing of PoE network cables, separate power feeds (if required), and any coaxial or accessory connections. Cable diameter limits depend on your specific cable gauge and jacket type; plan approximately 20–25mm usable space after accounting for weatherproof grommet thickness.

Q: Is the aluminum finish glossy or matte?

A: The white powder-coat finish (RAL9003) is matte, reducing glare and reflections that could interfere with nearby optical sensors or create visual distraction in low-light environments.

Q: What is the weight capacity of the SBP-300PMW2?

A: The mount base itself weighs 750g. Weight capacity depends on the camera housing and M10 attachment point strength, which should be confirmed in your specific camera or housing documentation. The straps and aluminum base are not the limiting factor in typical surveillance camera deployments (2–5 kg loads).

Q: Can I use this mount in coastal or high-salt-spray environments?

A: The aluminum construction with powder-coat finish and stainless steel straps are designed for corrosion resistance in harsh environments. However, regular inspection and rinsing (especially after salt spray events) will extend service life. Do not assume "corrosion-resistant" means "maintenance-free" in extreme coastal settings.

Ted Perry

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The SBP-300PMW2 is a straightforward, no-nonsense pole mount for fixed camera deployments. If you're specifying a surveillance system where cameras need to live on existing poles — parking lots, perimeter fencing, utility corridors, remote facility monitoring — this base handles the mechanical job cleanly.

Technical Highlights:

• Stainless steel straps with aluminum construction: You're looking at real corrosion resistance here. In a typical retail or industrial environment, this holds up 10+ years without repainting. In coastal or salt-spray zones, inspect annually — the finish will outlast painted steel by a factor of 3–5.
• M25 cable passage: Keeps cables organized and protected. Single conduit pass-through beats surface-mounted cable trays for aesthetics and weather resistance — cable doesn't sit exposed to UV, thermal cycling, or bird damage.
• Minimal footprint (185 × 115 × 40mm): Doesn't add visual bulk to poles. Matters on busy utility corridors or where architectural review restricts equipment profile.

Deployment Considerations:

• Verify pole diameter beforehand — 80mm minimum is typical for light utility poles but not all structural members meet this. Undersized poles require custom strapping solutions, which defeat the point of buying this mount.
• The M10 camera attachment point is solid, but verify your specific housing or camera bracket uses M10 female threads. Hanwha housings do; third-party gear sometimes uses different pitch or diameter. One strap wrench and a level will save installation time.

Use the SBP-300PMW2 for fixed pole-mounted camera systems in commercial or industrial settings where weather resistance, corrosion durability, and organized cable routing are non-negotiable. It's not fancy, but it stays put and weathers UV, rain, and temperature swings without fuss.
