Hanwha SBO-140BW Aluminum Backbox for Bullet Camera
The Hanwha SBO-140BW (often searched as SBO 140BW) is a purpose-built aluminum backbox engineered to house, protect, and route cables for Hanwha bullet cameras in outdoor surveillance deployments. This is not a generic mount — it solves a specific problem: exposed cable runs degrade in UV, moisture, and temperature swings. The backbox seals the cable entry point and provides a weatherproof junction between the camera and wall or conduit runs, extending the life of your installation and improving the visual footprint.
Key Features
- IP66 and IK10 environmental ratings: IP66 means the backbox blocks direct rain jets and dust ingress — you can spray it with a hose without water entering. IK10 rating means it resists impacts equivalent to 20 joules (roughly a 5 kg mass dropped from 40 cm), so casual vandalism and impact from ladders or tools won't crack the housing. Both ratings matter in outdoor perimeter and parking lot installations where exposure is non-negotiable.
- Aluminum construction, 980g weight: Aluminum is corrosion-resistant and significantly lighter than steel or zinc-plated steel backboxes. At under 1 kg, one technician can install it without a second person. The dark grey finish is intentionally neutral — it won't draw attention in professional environments.
- ø147.5 × 73.3mm compact footprint: This is tight enough that it doesn't create a bulk at the camera head on a building edge or pole. The small diameter minimizes wind loading on outdoor masts and doesn't interfere with adjacent fixtures.
- 26.5mm conduit hole: Standard conduit fittings slip through without modification. You can run three-quarter-inch flex conduit directly into the backbox, which keeps cable runs organized and protected from UV and rodent damage over long runs.
- Designed for QNO-6082R compatibility: The SBO-140BW is engineered specifically for Hanwha's QNO-6082R bullet camera. Mounting bosses and cable pass-throughs are aligned for this model, so cable routing is predictable and cable strain is minimized.
- Low-profile installation footprint: Unlike bulky junction boxes, the backbox sits flush against the wall or pole, reducing snag points and keeping the overall assembly sleek. This is important for high-traffic areas or where aesthetics matter (retail, campus, government buildings).
Integration & Compatibility
The SBO-140BW is a dedicated accessory for outdoor IP camera deployments. Verify your camera model against the QNO-6082R before ordering — backboxes are mount-specific and swapping models typically requires different hole spacing or cable routing. If you're specifying a camera that doesn't list the SBO-140BW as a compatible backbox, check the camera's datasheet for the correct backbox partnumber or consider a universal aluminum backbox if flexibility is more important than engineered fit.
When planning your cabling strategy, the 26.5mm conduit hole is your anchor point. Run conduit from the backbox down the wall to a surface-mount tray or through-wall junction. This approach keeps cables out of weather and sunlight, which extends both the cable jacket life and the PoE injector's working environment. For NVR power budgeting, confirm your camera's power draw and ensure your PoE switch has sufficient headroom; the backbox itself draws no power.
Typical Deployment Scenarios
The SBO-140BW is a standard component in outdoor perimeter security (building edges, fence lines), parking lot surveillance (pole-mounted or wall-mounted cameras), and industrial facility monitoring (exposed exterior walls, loading docks). Any installation where the camera and cable entry are exposed to rain, dust, or temperature swings benefits from this level of sealing. If you're mounting in a covered soffit or indented eave where water spray is unlikely, a simpler bracket may suffice — reserve the SBO-140BW for true outdoor exposure.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
I spec the SBO-140BW when I'm mounting Hanwha bullets outdoors and need a clean, weatherproof cable termination without the bulk of a traditional junction box. The IP66 and IK10 ratings aren't just checkboxes — they mean you can install this in a parking structure or loading dock where it'll take spray-down cleaning and the occasional bump from a ladder without cracking or letting water migrate into your cable runs. The 26.5mm conduit hole is sized right for three-quarter-inch flex, so you're running protected cable all the way to the camera head instead of leaving six inches of jacket exposed to UV.
One watch-out: this backbox is dimensioned for the QNO-6082R and similar form-factor Hanwha bullets. If you're mounting a different model or a third-party camera, measure the base diameter and mounting pattern before you order. The bosses won't line up on incompatible bodies, and you'll end up with an awkward gap or need to drill new holes. For Hanwha-native deployments, though, it's a solid piece that keeps installs looking professional and lasting longer.
