Viking Electronics Q171060 Handset with Armored Cord

Overview

The Viking Electronics Q171060 is a telephone handset with armored cord designed for rugged, tamper-resistant communication installations. It draws power directly from the telephone line (70–150V AC at 16–67 Hz), eliminating any need for a local power supply or additional wiring runs — a practical advantage in retrofit entry phone installs where running separate power is impractical. The REN rating of 0.4A keeps load on shared lines minimal, and the 70–90 dB ring volume range ensures audibility in noisy commercial environments such as loading docks, warehouses, or industrial lobbies.

Compatibility

The Q171060 is intended for use with Viking Electronics analog entry phone and intercom systems. The associated kit documentation references the Q170600 series, which includes a capacitor and ringer module — indicating this handset pairs with that assembly in Viking's analog door entry phone line. Compatible deployment contexts include Viking E-Series indoor and outdoor entry phones (such as the E-10A and E-20B), which provide two-way communication at commercial doors and gates. Confirm handset termination type against your specific Viking panel model before ordering.

Installation Notes

Operating temperature range is -4°F to 149°F (-20°C to 65°C), making this handset viable for unconditioned vestibules, exterior enclosures with cover protection, and industrial spaces with high ambient heat. Humidity tolerance is 5% to 95% non-condensing — not rated for condensing environments, so avoid direct outdoor exposure without a weatherproof housing. Physical footprint is compact at 1.40" x 1.6" x 1.23", fitting standard handset mounting brackets. Shipping weight is 1 lb. No external power connection required; the handset operates entirely off loop current from the telephone line.
