Vertiv GXT5-2000LVRT2UXLN Online Double Conversion Rack/Tower UPS
Overview
The Vertiv GXT5-2000LVRT2UXLN is a 2000VA / 1800W online double conversion UPS in a 2U rack/tower convertible form factor — built for server rooms, network closets, and security infrastructure where a momentary input blip cannot be tolerated. Unlike standby or line-interactive designs that switch to battery after detecting a fault, double conversion continuously regenerates clean 120VAC output regardless of what's happening on the utility feed. That means zero transfer time, and it means power-hungry IP camera recorders, access control servers, and network switches never see the raw grid. If you're protecting a network video recorder stack or a dense PoE switch bay, the GXT5-2000LVRT2UXLN (often searched as GXT5 2000LVRT2UXLN) is sized and specified for exactly that.
Key Features
- 2000VA / 1800W Double Conversion Topology: Every watt of load draws from a continuously inverted, battery-backed output — not from utility pass-through. Sags, surges, and browndowns on your 120V feed are invisible to connected equipment. The 1800W real-power rating gives you roughly 90% power factor, which is accurate headroom planning for modern switching power supplies.
- Up to 98% Efficiency in Active ECO Mode: In ECO mode the unit idles at 98% efficiency, dropping heat output and utility costs significantly versus a conventional online UPS running at 94–95%. On-line mode holds 95%. For a 24/7 installation, the difference over three years is measurable on the power bill — and in a sealed network closet, less heat means longer equipment life.
- Wide Input Voltage Range (60–150V): The unit accepts utility input anywhere from 60 to 150VAC before switching to battery, which is unusually wide for a 120V-class UPS. In areas with chronic undervoltage or in buildings with aging electrical infrastructure, this range keeps the batteries from cycling constantly — extending battery service life.
- 7 Output Receptacles with 4 Individually Programmable Outlets: The output bank includes 1× L5-20R and 6× 5-20R receptacles. Four of the 5-20R outlets are individually programmable — you can sequence startup loads, shed non-critical devices during a battery event, or schedule outlet cycling for reboots. The remaining 3 (1× L5-20R + 2× 5-20R) are always-on non-programmable. NEMA L5-20P input plug matches standard 20A twist-lock circuits in equipment rooms.
- Colored Gravity-Sensing LCD Control Panel: The display reorients automatically when the chassis is rotated between rack and tower positions — a small but genuinely useful feature when you're standing the unit on its side during a rack build-out. UPS status, load percentage, runtime, and fault codes are readable without a laptop or phone.
- USB, RS485, RS232, and Terminal Block Interface: Out of the box, the GXT5-2000LVRT2UXLN connects to a host via USB for graceful shutdown integration with Windows/Linux servers. RS232 and RS485 add serial management for legacy BMS or SCADA environments. The terminal block output supports dry-contact integration with building management systems without requiring a network card.
- Optional Vertiv Liebert IntelliSlot RDU120 for SNMP/Web Management: The included RDU101 card (per the product name) enables SNMP and web-based management — meaning you can poll UPS status, set thresholds, and receive traps from your NMS without a separate serial connection. This is the correct path for integrating into a VMS-managed security infrastructure where all devices report to a central monitoring dashboard.
- ENERGY STAR 2.0, UL 1778, RoHS2, and REACH Listed: ENERGY STAR 2.0 certification confirms independently verified efficiency performance. UL 1778 (4th edition) is the UL safety standard for UPS equipment — required for many commercial building permits and insurance compliance. RoHS2 and REACH compliance satisfy EU regulatory requirements for any project with cross-border equipment procurement.
- Compact 2U Rack/Tower Convertible Chassis (16.9 × 18.5 × 3.4 in, 47.5 lb): At 3.4 inches tall, the GXT5-2000LVRT2UXLN takes 2U in a standard rack. The chassis converts to tower orientation for floor or shelf mounting without additional hardware. At 47.5 lb, plan for two people on a rail slide — this is not a one-person rack job at 2U density.
Integration and Compatibility
The GXT5-2000LVRT2UXLN is designed for standard North American 120V / 20A circuits (NEMA L5-20P input). Output voltage is user-configurable across 110, 115, 120, and 125VAC at ±3% regulation, which covers the full tolerance range of standard IT and IP surveillance equipment. The IntelliSlot expansion bay accepts Vertiv Liebert network management cards for SNMP integration — the RDU101 card included with this model enables SNMP and web management immediately without purchasing an add-on card separately. External battery connector support means runtime can be extended with compatible external battery cabinets when protection windows need to exceed what the internal batteries provide. Operating temperature range of +32 to +104°F (0 to 40°C) covers conditioned server rooms and most telecom closets; installations in unconditioned spaces above 40°C will void the specification envelope. For full Vertiv UPS and power infrastructure options, the GXT5 family spans multiple power ratings and form factors.
Frequently Asked Questions
Q: What is the topology of the GXT5-2000LVRT2UXLN — is it a line-interactive or true online UPS?
A: It is a true online double conversion UPS. The inverter continuously regenerates the output waveform, so connected equipment never draws directly from utility — transfer time is effectively zero. This is the correct topology for protecting NVRs, servers, and network infrastructure where even a 4ms transfer window is unacceptable.
Q: Can the GXT5-2000LVRT2UXLN be used in both rack and tower orientations?
A: Yes. The chassis is convertible between 2U rack and tower/shelf configurations. The colored LCD control panel includes gravity sensing and automatically reorients its display based on chassis position, so it remains readable in either orientation without manual adjustment.
Q: What output receptacles does the GXT5-2000LVRT2UXLN provide, and how many are controllable?
A: The unit provides 1× NEMA L5-20R and 6× NEMA 5-20R receptacles — seven total. Four of the 5-20R outlets are individually programmable for load sequencing or outlet cycling. The remaining three (1× L5-20R + 2× 5-20R) are non-programmable always-on outlets.
Q: Does the GXT5-2000LVRT2UXLN include network management, or is that an add-on?
A: This model includes the RDU101 communications card, which enables SNMP and web-based management out of the box. For additional or alternative management card options, the IntelliSlot expansion bay is compatible with Vertiv Liebert IntelliSlot RDU120 and other cards in the IntelliSlot family.
Q: What certifications does the GXT5-2000LVRT2UXLN carry?
A: The unit is ENERGY STAR 2.0 certified, UL 1778 (4th edition) listed, CSA 22.2 No. 107.1 listed, and compliant with RoHS2, REACH, and WEEE directives. UL 1778 listing is the primary safety certification required for commercial building compliance in North America.
Q: What input voltage range does the GXT5-2000LVRT2UXLN tolerate before switching to battery?
A: The unit accepts input from 60 to 150VAC before transferring to battery — a wide range that prevents unnecessary battery cycling in facilities with known undervoltage or overvoltage conditions. The nominal input is 120VAC from a standard NEMA L5-20P 20A circuit.
The GXT5-2000LVRT2UXLN is one of the better-specified 2U units in the 2000VA class for security infrastructure — specifically because the 60–150V input range and zero-transfer-time double conversion topology address two of the most common failure modes I see in camera and access control deployments: chronic undervoltage killing batteries prematurely, and brief transfer windows causing NVR write errors during grid events.
Technical Highlights:
- 98% ECO / 95% Online Efficiency: At 2000VA running 24/7, the gap between 95% and 91% (a typical older online UPS) translates to roughly 70–80W of continuous heat reduction in the rack — meaningful in a sealed 2U stack in a closet with marginal airflow.
- 4 Programmable 5-20R Outlets: Load sequencing matters when you're powering NVRs, PoE switches, and servers from a single UPS. Program non-critical loads to shed first during a battery event and you extend runtime for the devices that actually need it — camera recorders and access control panels — without guesswork.
- Wide 60–150VAC Input Range: This is the spec most buyers skip over. In older commercial buildings or facilities on the tail end of a long utility run, input voltage can dip to 100–105VAC regularly. A UPS with a narrow input window (e.g., 90–140V) will cycle batteries constantly in those conditions. The GXT5-2000LVRT2UXLN stays on utility down to 60V, which is well below any real browndown threshold.
Deployment Considerations:
- The NEMA L5-20P input plug requires a dedicated 20A twist-lock circuit. If your rack PDU or wall outlet is straight-blade 5-20R, you'll need an adapter or circuit change — plan this before the install date, not during it.
- At 47.5 lb in a 2U form factor, this is a two-person rack mount. The depth is 18.5 inches, so verify your rack's usable depth (not just nominal depth) accommodates the unit plus cable management clearance at the rear.
For a security operations center or multi-camera NVR rack where the recorder, core switch, and access control panel all share the same UPS, the GXT5-2000LVRT2UXLN's programmable outlet sequencing and SNMP management via the included RDU101 make it a straightforward fit — particularly in deployments where the IT team needs to monitor UPS status alongside the rest of the network without a separate out-of-band serial connection.
