Vertiv 4114284 Concise Descriptor
Overview
The Vertiv 4114284 is a cable connector designed to interface with specific Vertiv GXT5 Uninterruptible Power Supply (UPS) models. This accessory ensures proper electrical connection for extended battery cabinets (EBCs), critical for maintaining uptime during power disruptions in sensitive IT environments. Proper connection is key to leveraging the full backup capacity of your UPS system.
Compatibility
This connector is engineered for use with the following Vertiv GXT5 UPS models:
- GXT5-EBC36VRT2U series: GXT5-750IRT2UXLE, GXT5-1000IRT2UXLE
- GXT5-EBC48VRT2U series: GXT5-1500IRT2UXLE, GXT5-2000IRT2UXLE
- GXT5-EBC72VRT2U series: GXT5-3000IRT2UXLE
- GXT5-EBC192VRT3U series: GXT5-5000IRT5UXLE, GXT5-6000IRT5UXLE, GXT5-8000IRT5UXLE, GXT5-10KIRT5UXLE
- GXT5-EBC384VRT6U series: GXT5-16KIRT9UXLE, GXT5-20KIRT9UXLE
Verify your UPS model number against this list to ensure correct pairing.
Installation Notes
Installation requires connecting the EBC to the UPS unit. Ensure the UPS is powered off and disconnected from mains power before attempting any connection. Refer to the specific UPS and EBC documentation for detailed wiring and connection procedures. Incorrect installation can lead to system malfunction or damage.
What's in the Box
- 1x Vertiv 4114284 Cable Connector
