Vertiv 25060591 Cable Connector
Overview
The Vertiv 25060591 is an external battery cabinet (EBC) cable connector designed to link specific Vertiv GXT5 series Uninterruptible Power Supply (UPS) units with their corresponding battery cabinets. This ensures a robust and reliable power path for critical IT equipment, preventing data loss and system downtime during power fluctuations or outages. Proper connection is essential for extending runtime and maintaining system integrity in rack-mounted server environments.
Compatibility
This connector is engineered for specific Vertiv GXT5 UPS models and their associated EBCs. It is compatible with the following configurations:
- GXT5-EBC36VRT2U for GXT5-500LVRT2UXL, GXT5-500LVRT2UXLN, GXT5-750LVRT2UXL, GXT5-750LVRT2UXLN, GXT5-1000LVRT2UXL, GXT5-1000LVRT2UXLN UPS units.
- GXT5-EBC48VRT2U for GXT5-1500LVRT2UXL, GXT5-1500LVRT2UXLN, GXT5-2000LVRT2UXL, GXT5-2000LVRT2UXLN UPS units.
- GXT5-EBC72VRT2U for GXT5-3000LVRT2UXL, GXT5-3000LVRT2UXLN, GXT5-3KL620RT2UXL, GXT5-3KL620RT2UXLN, GXT5-3KL630RT2UXL, GXT5-3KL630RT2UXLN UPS units.
- GXT5-EBC144VRT2U for GXT5-5000MVRT4UXLN, GXT5-6000MVRT4UXLN UPS units.
- GXT5-EBC192VRT3U for GXT5-5000HVRT5UXLN, GXT5-6KL630RT5UXLN, GXT5-8000HVRT5UXLN, GXT5-10KHVRT5UXLN UPS units.
- GXT5-EBC288VRT4U for GXT5-8000MVRT6UXLN, GXT5-10KMVRT6UXLN, GXT5-15KMVRT11UXLN, GXT5-20KMVRT11UXLN UPS units.
Verify your specific UPS model number against this list before ordering to ensure correct fitment.
Installation Notes
This connector facilitates the physical link between the UPS and its external battery cabinet. Ensure the UPS and EBC are powered off and disconnected from mains power before attempting installation. The connector is designed for a secure, plug-and-play connection, but proper seating is critical for uninterrupted power transfer. Refer to the specific UPS and EBC installation manuals for detailed wiring and connection procedures.
What's in the Box
- 1x 25060591 Cable Connector
