Geovision 84-CA22000-100U 2MP Cube IP Camera with PIR
Overview
The Geovision 84-CA22000-100U is a 2MP compact cube camera built for indoor and semi-outdoor retail, entrance, and access-monitoring environments where space constraints and discreet coverage are priorities. The 84-CA22000-100U delivers clear, detailed video at 2 megapixel resolution with H.264 compression, reducing bandwidth load compared to higher-resolution alternatives—a real advantage on congested network segments or storage-constrained systems. Wide Dynamic Range (WDR) preserves detail in mixed-lighting scenes (backlit doorways, windows, skylights) without the halo artifacts that plague cheaper WDR implementations. Integrated PIR (Passive Infrared) motion detection enables rule-based alerts and smart recording triggers, cutting storage waste by capturing only when activity occurs in monitored zones and reducing false-positive alerts from non-threatening motion.
Compatibility
This camera integrates with any standard ONVIF-compliant VMS platform (Geovision GV-Center, Milestone, Genetec, etc.) and IP surveillance infrastructure supporting H.264 video streams. PoE (802.3af) powering at 15.4W max means it works with any standard switch or injector delivering 802.3af budget without straining power allocation across multi-camera deployments. The compact cube form factor and 3.35mm lens mount with flexible mounting options suit ceiling, wall, or recessed installation in modern architectural spaces where bulkier housings create clutter or obstruction.
Installation Notes
Draws 15.4W via PoE—well within 802.3af limits (13W sustained budget per port), so no separate power supply needed at the camera. Single CAT5e/CAT6 run handles both power and video. No environmental enclosure required for semi-outdoor use under covered eaves or protected soffits, but skip this model for direct-rain or high-humidity exposed mounting—that requires higher IP ratings than this compact design provides.
