Panduit GCE500-250-X Concise Descriptor
Overview
The Panduit GCE500-250-X is a Grounding Style E connector designed for 250-500 kcmil wire. It provides a secure and reliable electrical connection essential for proper grounding in industrial and commercial installations. This connector is engineered to meet stringent electrical codes and ensure system integrity, particularly in environments where robust grounding is critical for safety and equipment protection. The GCE500-250-X is suitable for applications requiring a high-capacity, dependable grounding point.
Compatibility
This connector is designed for use with wire sizes ranging from 250 kcmil to 500 kcmil. It is compatible with standard grounding busbars and termination points that accept Style E connectors. While specific system compatibility depends on the overall grounding design, its primary function is to terminate conductors for connection to grounding infrastructure.
Installation Notes
For optimal performance and safety, the Panduit GCE500-250-X requires specific installation procedures. It is designed for crimp termination using Panduit's recommended crimping tools and die sets appropriate for the 250-500 kcmil wire range. Ensure the wire strands are fully contained within the connector barrel before crimping. Proper torque must be applied when connecting the terminated wire to the grounding busbar or terminal, following relevant electrical codes and standards to ensure a low-resistance path to ground.
What's in the Box
- 1x Panduit GCE500-250-X Grounding Connector
