Panduit PV14-10F-C Fork Terminal

Overview

The Panduit PV14-10F-C is a blue, vinyl-insulated fork terminal designed for secure electrical connections in 16-14 AWG wire gauge applications. It provides a reliable termination point for #10 studs, ensuring proper current flow and preventing conductor damage in control panels, power distribution units, and other electrical enclosures. This terminal is rated for 600V and a maximum insulation temperature of 105°C (221°F), meeting UL 94V-0 flammability standards for safe installation in sensitive environments.

Compatibility

This terminal is designed for use with #10 stud sizes and is compatible with wire ranging from 16 to 14 AWG. Its blue color-coding adheres to industry standards for easy identification of wire gauge. It is suitable for general electrical wiring applications where secure, insulated termination is required.

Installation Notes

The terminal features a .34 inch width and .24 inch clearance, accommodating standard #10 studs. The maximum insulation diameter it can accept is .170 inches, with a stock thickness of .03 inches. Proper crimping with a compatible tool is essential to ensure the rated electrical performance and mechanical integrity of the connection. The vinyl insulation offers protection against short circuits and environmental factors up to its specified temperature and voltage limits.

What's in the Box

  • 1x Panduit PV14-10F-C Fork Terminal
Expert Analysis
Specifications
UL Flammability: UL 94V-0
Maximum Insulation Temperature: 221°F (105°C)
Voltage Rating: 600 V
Length: .92 In.
Width: .34 In.
Clearance: .24 In.
Max Insulation: .170 In.
Panduit Color Code: Blue
Stock: .03 In.
Stud Size: #10
Wire Range: 16 – 14 AWG
RoHS Compliancy Status: Compliant
Q&A
Reviews
Product Video

Panduit FORK TERMINAL VINYL INSULATED 1 - PV14-10F-C

$76.62
$75.99
Add to Cart
