Panduit FRA2X2LBL FiberRunner 2x2 Angled Fitting - Black

Panduit FRA2X2LBL FiberRunner 2x2 Angled Fitting

The Panduit FRA2X2LBL is a 90-degree angled fitting designed for 2x2 inch FiberRunner cable management systems, enabling controlled directional changes in high-density fiber pathways without violating minimum bend radius requirements. Constructed from impact-resistant polycarbonate/ABS blend and UL Listed to 2024A for optical fiber cable routing assemblies, this fitting serves data centers, telco central offices, and carrier-grade network facilities where pathway integrity and compliance documentation matter. Measuring 7.29 inches square with a 2.08-inch profile, it integrates seamlessly into FiberRunner horizontal and vertical runs, maintaining the enclosed-raceway protection that prevents accidental damage during maintenance or adjacent infrastructure work.

Key Features

• 90-degree angled fitting for 2x2 inch FiberRunner systems — manages pathway direction changes at corners, vertical-to-horizontal transitions, or equipment-rack interfaces
• Polycarbonate/ABS construction — impact-resistant blend withstands installation handling and long-term environmental exposure in mechanical rooms
• UL 2024A Listed for optical fiber cable routing assemblies — meets National Electrical Code (NEC) Article 770 requirements for communications raceways
• Telcordia GR-63-CORE Level 3 compliant — passes Network Equipment Building System (NEBS) tests for telco and carrier-grade deployments
• 7.29 x 7.29 inch footprint with 2.08-inch height — provides generous internal clearance for multi-connector trunk assemblies and pre-terminated harnesses
• Black finish — matches standard FiberRunner pathway components for consistent visual appearance across structured cabling installations
• RoHS compliant — meets European Union restrictions on hazardous substances for environmentally responsible procurement

The FRA2X2LBL fitting uses the same polycarbonate/ABS material formulation as Panduit's full FiberRunner product line, delivering impact resistance superior to PVC alternatives while maintaining flame-spread ratings required for plenum-adjacent installations. The UL 2024A Listing verifies that the assembly meets optical fiber cable routing standards, a critical compliance checkpoint for inspections in municipal data centers, carrier hotels, and other Authority Having Jurisdiction (AHJ) environments. Telcordia GR-63-CORE Level 3 compliance extends beyond basic NEC requirements to address seismic, temperature cycling, and humidity resistance tests specified by telecommunications carriers — meaning the fitting is suitable for CLEC aggregation facilities, MSO headend builds, and other regulated network infrastructure projects where generic cable pathway fittings would fail audit. The 2x2 inch internal dimension accommodates up to 288-fiber trunk assemblies or multiple 72-fiber harnesses routed in parallel, with sufficient clearance to prevent compression of factory-terminated connectors during installation.

Installers use the FRA2X2LBL at equipment-row ends where FiberRunner horizontal ladder transitions to vertical risers, at perimeter-wall corners in cage-and-corridor colocation suites, and at optical distribution frame (ODF) interfaces where structured pathways terminate into patch-panel zones. The angled geometry maintains minimum bend radius for single-mode and multimode trunks — typically 10x cable diameter for OS2 and OM3/OM4 assemblies — preventing insertion-loss degradation that occurs when field crews force oversized bundles through improvised transitions. Each fitting ships as a single unit (carton quantity of five supports multi-row deployments), with snap-together coupling to adjacent FiberRunner sections that eliminates the need for fasteners or adhesive. The black polycarbonate finish resists UV degradation under high-bay lighting and hides dust accumulation better than light-gray alternatives, reducing the visible-maintenance burden in customer-facing white-space areas.

The FRA2X2LBL's dual compliance — UL 2024A for NEC Article 770 and Telcordia GR-63-CORE for carrier NEBS requirements — makes it the correct choice for mission-critical fiber deployments where pathway failure or standards non-conformance triggers service-level agreement penalties. Unlike generic corner fittings that lack third-party testing documentation, the Panduit fitting provides the UL file number and Telcordia test-report references that commissioning inspectors require for sign-off. For contractors managing hyperscale build-outs, multi-tenant colocation expansions, or carrier-neutral meet-me-room installations, this fitting eliminates the rework risk associated with non-listed pathway components discovered during final inspection.
