Middle Atlantic EVO 45 CUT OUT Template - EFB45-TEMPLATE

Middle Atlantic EFB45-TEMPLATE EVO 45U Rack Cutout Template

Overview

The Middle Atlantic EFB45-TEMPLATE is a physical cutout template designed for field fabrication work on EVO series 45U rack enclosures. When an installation requires custom panel cutouts — for cable pass-throughs, ventilation openings, or component mounting holes — precise positioning matters. The EFB45-TEMPLATE gives installers a repeatable reference guide to mark and cut accurately without measuring from scratch on each enclosure, reducing rework and keeping rack builds consistent across multi-cabinet deployments.

Compatibility

Designed for use with the Middle Atlantic EVO series 45U rack enclosures. Verify fit against your specific EVO enclosure model before ordering — Middle Atlantic offers the EVO line in multiple widths and depths, and template geometry is tied to the enclosure panel dimensions. If you are working with a different U-count EVO variant or a non-EVO rack enclosure, confirm template compatibility with the enclosure's panel spec before use.

Installation Notes

Use the template as a marking guide on the enclosure panel before cutting. Standard sheet-metal fabrication practices apply: center-punch marked locations before drilling to prevent bit walk, use appropriate hole saws or chassis punches sized to your pass-through or grommet hardware, and deburr all cut edges to protect cable jackets. The template itself does not include cutting tools or hardware — have your punch-down kit, drill, and appropriate bits on hand before starting.
