Panduit DUCT COVER PVC 3W X 6 WHITE - C3WH6

Panduit C3WH6 3-Inch PVC Snap-On Duct Cover, 6 ft White

Overview

The Panduit C3WH6 is a 3-inch-wide, 6-foot PVC snap-on duct cover designed to close off open-top wire management duct runs in control rooms, server rooms, IDF closets, and structured cabling environments. At 3.25 inches overall width and just 0.37 inches in profile height, the C3WH6 seats flush over standard Panduit duct bodies without tools, keeping cable runs protected and visually clean. If you are managing horizontal cable trays or vertical runs in a telecom room and need a cover that installs in seconds and meets major compliance requirements, this is the part.

Key Features

• Snap-On Installation: The snap-on mount method means no screws, no hardware, and no special tools — the cover seats directly onto compatible duct bodies by hand. On a long cable management run with dozens of sections, that installation speed compounds quickly compared to fastener-based covers.
• 6-Foot Section Length: Each C3WH6 covers 1.8 meters (6 ft) of duct run per piece. Fewer joints per linear foot of pathway means a cleaner finished appearance and fewer potential points where covers can work loose over time.
• 3-Inch Duct Width Coverage: With a duct width of 3 inches (76.2 mm) and an overall width of 3.25 inches (82.6 mm), the C3WH6 is matched to 3-inch Panduit duct bodies. Verify your duct body width before ordering — this cover will not seat correctly on 2-inch or 4-inch duct.
• Low-Profile at 0.37 Inches: The 9.4 mm cover height adds minimal bulk to an existing duct assembly. In tight panel interiors or densely populated cable trays where clearance to adjacent components is limited, the thin profile prevents interference.
• UL94 V-0 Flammability Rating: V-0 is the most stringent self-extinguishing rating under the UL 94 standard — the material stops burning within 10 seconds of flame removal and does not produce flaming drips. For any installation governed by NEC, building codes, or data center fire safety standards, V-0 PVC satisfies the requirement without needing a separate plenum-rated product in most applications.
• White PVC Construction: PVC provides dimensional stability in typical indoor temperature ranges and resists the UV degradation and chemical exposure common in light industrial environments. White color integrates with standard telecom room and office cabling aesthetics and simplifies cable plant audits — color-coded duct management is easier to document photographically.
• Multi-Standard Compliance (UL Recognized, CSA Certified, CE Compliant, RoHS Compliant): A single part satisfies North American (UL, CSA) and European (CE, RoHS) compliance requirements simultaneously. For projects with global procurement or multi-site rollouts spanning US and EU facilities, that breadth of certification eliminates the need to qualify a separate regional SKU.

Integration & Compatibility

The C3WH6 is engineered for use with Panduit's wire management duct system. It is intended for open-slot duct bodies in the 3-inch-width class. When planning a full duct run, pair this cover with the matching Panduit wire management duct body and any required fittings — inside corners, outside corners, tees, and reducers — to maintain a closed, continuous pathway. For larger cable populations requiring wider pathways, Panduit offers covers in 2-inch, 4-inch, and wider profiles within the same Panduit catalog; verify the duct body width before substituting covers. The RoHS compliance status makes the C3WH6 suitable for incorporation into finished equipment assemblies destined for the EU market, where RoHS documentation is required at the component level.

In rack and enclosure deployments, this cover works alongside horizontal and vertical cable managers to complete a fully enclosed cabling pathway from patch panel to switch. For IP security and IP camera infrastructure where neat cable routing through control rooms is part of a professional installation standard, snap-on covers like the C3WH6 are a practical finishing component.

Frequently Asked Questions

Q: What duct body width is the C3WH6 designed to fit?

A: The C3WH6 is designed for 3-inch (76.2 mm) wide Panduit duct bodies. Its overall width is 3.25 inches (82.6 mm). It will not properly seat on 2-inch or 4-inch duct bodies.

Q: How does the C3WH6 attach — do I need screws or tools?

A: No tools or fasteners are required. The C3WH6 uses a snap-on mount method and seats directly onto the duct body by hand.

Q: What is the flammability rating on the C3WH6?

A: The C3WH6 carries a UL94 V-0 flammability rating, the most stringent self-extinguishing classification under UL 94. The material self-extinguishes within 10 seconds and produces no flaming drips.

Q: What compliance certifications does the C3WH6 hold?

A: The C3WH6 is UL Recognized, CSA Certified, CE Compliant, and RoHS Compliant — covering both North American and European regulatory requirements.

Q: How long is each C3WH6 cover section?

A: Each section is 6 feet (1.8 meters) in length.

Q: Is the C3WH6 suitable for outdoor installations?

A: The C3WH6 is a PVC snap-on duct cover with no IP or NEMA environmental rating listed. It is intended for indoor wire management applications. For outdoor or wet-location cable management, consult Panduit's outdoor-rated conduit and duct product lines.

Jerry Tildsen

The C3WH6 is the kind of part that gets overlooked in project BOM reviews until someone notices the duct bodies are open in a finished installation. The UL94 V-0 rating is the detail that matters most here — not every snap-on PVC cover in the 3-inch class carries V-0, and for any data center or commercial building project where the AHJ (Authority Having Jurisdiction) reviews cable management materials, a V-0 rating on the C3WH6 keeps the inspection clean without substitution late in the project.

Technical Highlights:

• UL94 V-0 PVC: Self-extinguishing within 10 seconds with no flaming drips — satisfies NEC and most building-code cable management material requirements in indoor commercial environments without upgrading to a more expensive plenum-rated assembly.
• 6 ft (1.8 m) Sections: Longer sections mean fewer joints per run. On a 20-foot horizontal cable manager, you need four sections instead of ten 2-foot pieces — fewer snap points, faster installation, cleaner audit photos.
• 3.25-Inch Overall Width on a 3-Inch Duct: The 0.25-inch overhang seats the cover securely on the duct flanges. Do not attempt to use this cover on duct bodies wider than 3 inches — the snap engagement geometry is specific to the 3-inch duct family.

Deployment Considerations:

• Confirm the duct body model number before ordering covers. Panduit's 3-inch duct bodies and the C3WH6 are matched components — mixing widths results in covers that will not seat or will seat loosely and pop off under cable movement.
• The 0.37-inch (9.4 mm) cover height is minimal, but factor it into clearance checks if the duct run passes near panel doors, hinged frames, or equipment rails where even a fraction of an inch of additional height can cause interference.

The C3WH6 is a straightforward finishing component for structured cabling installations in IDF/MDF rooms, security operations centers, and enterprise LAN closets where UL/CSA/CE compliance documentation is required at the component level for project closeout packages.
