DSC HS2ICNP Proximity Keypad Reader

DSC HS2ICNP Proximity Keypad Reader

Overview

The DSC HS2ICNP is a dual-technology proximity and keypad reader designed for secure access control installations. This compact reader combines proximity card detection with integrated keypad functionality, delivering credential flexibility for integrators managing mixed-credential environments. The HS2ICNP operates at 12VDC and features a 64-icon LCD display for real-time status indication and user feedback during access events.

Key Features

• Dual-Technology Design: Proximity and keypad reader in a single unit reduces installation complexity and footprint requirements
• 64-Icon LCD Display: Provides visual feedback during credential presentation and system status monitoring
• Compact Form Factor: Measures 168 x 122 x 20 mm (6.6 x 4.8 x 0.8 inches), enabling flexible mounting in tight or retrofit applications
• 12VDC Operation: Standard voltage requirement simplifies power distribution and integrates with existing access control infrastructure
• White Finish: Neutral appearance suitable for diverse facility environments and aesthetic requirements
• Wide Operating Temperature Range: Rated 0°C to 49°C (32°F to 120°F), supporting indoor and temperature-controlled facility deployment

Integration & Compatibility

The HS2ICNP is engineered for integration with DSC and third-party access control systems supporting standard proximity and keypad input protocols. Security integrators should verify controller compatibility with dual-technology reader inputs and confirm power supply capacity for 12VDC operation. The reader's compact dimensions and standard mounting footprint allow retrofit installations without structural modification. Integration with door control modules, electric strikes, and magnetic locks follows conventional access control wiring practices. Credential management and user enrollment typically occur at the system controller level, independent of reader configuration.

Technical Specifications

Operating voltage is 12VDC with standard access control system integration. The reader operates reliably across 0°C to 49°C environmental conditions, accommodating both climate-controlled and transitional spaces. The white color finish resists soiling in high-traffic areas. The 64-icon LCD display provides sufficient visual feedback for diagnostic and operational purposes. The reader's 20 mm depth permits installation in surface-mount or semi-flush applications. Weight and detailed communication protocol specifications are not provided in standard documentation; verify exact specifications with DSC technical resources for system-specific integration requirements.

Karl Wilson

I've specified the DSC HS2ICNP in mixed-credential access control environments where facilities require both proximity card and PIN keypad support without adding multiple reader devices. This dual-technology approach reduces controller input load and simplifies credential issuance strategies. The compact footprint has proven valuable in retrofit installations where space around door frames is limited.

Technical Highlights:

• Dual Reader Functionality: Proximity and keypad in a single device eliminates multiple hardware layers at entry points
• LCD Status Display: The 64-icon display provides immediate feedback during credential presentation, useful for troubleshooting access denial events
• Thermal Range: 0°C to 49°C operating window accommodates both interior and controlled exterior vestibule installations

Deployment Considerations:

• Confirm that your access control panel supports dual-technology reader input cards or protocol converters before specifying the HS2ICNP
• Verify 12VDC power supply capacity; dual-technology readers may draw higher current than single-mode devices, particularly with LCD display operation
• Plan credential issuance workflow to leverage both proximity and PIN authentication—consider whether your system requires both or uses keypad as a fallback method

The HS2ICNP remains a practical choice for access control deployments balancing credential flexibility with hardware consolidation. Its compact dimensions and straightforward 12VDC requirement make integration straightforward in most standard installations. Verify system controller compatibility and power budgets before order placement.
