Scanner Type:
Corded Imager
Color:
Twilight Black
Dimensions:
6.5 in. H x 2.6 in. W x 3.9 in. D
Weight:
5.7 oz. / 161.9 g
Input Voltage Range:
4.5 to 5.5 VDC
Operating Current:
340 mA (typical)
Standby Current:
150 mA (typical)
Host Interface:
USB, RS232, TGCS (IBM) 46xx over RS485
Decode Capability 1D:
Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32
OCR Capability:
OCR-A, OCR-B, MICR, US Currency
Image Sensor:
1280 x 800 pixels
Minimum Print Contrast Resolution:
15% minimum reflective difference
Skew Tolerance:
+/- 60°
Pitch Tolerance:
+/- 60°
Roll Tolerance:
0° - 360°
Operating Temperature:
32.0° to 122.0° F / 0.0° to 50.0° C
Storage Temperature:
-40.0° to 158.0° F / -40.0° to 70.0° C
Humidity:
5% to 95% RH, non-condensing
Drop Specification:
Designed to withstand multiple drops at 6.0 ft./1.8 m to concrete
Tumble Specification:
Designed to withstand 2,000 tumbles in 1.5 ft./0.5 m tumbler
Environmental Sealing:
IP52
Electrostatic Discharge Immunity:
ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect
Ambient Light Immunity:
0 to 10,000 foot candles/0 to 107,000 Lux
User Indicators:
Direct Decode Indicator, Good Decode LEDs, rear view LEDs, beeper
Warranty:
Five Years
