Type:
Bullet
Features:
IR
Frame Rate:
Variable
Active Pixels:
3840 (H) x 2160 (V)
Sensor Type:
4K 1/2.8" CMOS sensor
Max Resolution:
4K
Minimum Scene Illumination in color:
0.0 lux (B/W), 0.09 lux (color)
Test Video Output:
Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels:
3952 (H) x 2320 (V)
Advanced Lens Features:
Auto focus, Motorized zoom, P-iris
Focal Length:
2.7mm ~ 13.5mm
Horizontal Field of View (HFOV:
90.3° ~ 33.1°
IR Distance:
140' range Smart IR™
Lens Type:
Vari-focal Lens
Vertical Field of View (VFOV:
18.9°~49
Audio compression:
G.711
I/O Alarm in/out:
1 input, 1 output
I/O Audio in/out:
1 audio in, 1 audio out
IVA license:
Intrusion, line crossing, counting line, loitering, enter, exit, tamper
IVA+ license:
Logical rules, object removed, tailgating, direction, stopped, appear, disappear, object left
3D digital noise reduction:
Smart DNR™ 3D Digital Noise Reduction
Auto gain control:
Auto
Backlight compensation (BLC:
Yes
Day and Night:
Auto day/night, Day (color), Night (B/W)
De-fog:
Yes
Memory slot:
Micro SD/SDHC/SDXC, up to 1TB
Mirror/flip:
Yes
Motion Detection:
Yes
Operational Notifications:
Alarm output, Email, FTP, SD card
Privacy Zones:
16 programmable privacy masks
Sharpness:
Yes
Shutter Mode:
Anti-Flicker, Auto, Manual, Slow Shutter
Shutter Speed:
1/15 ~ 1/32000
Slow Shutter Speed:
Off, x10, x2, x3, x5, x6, x7.5
White Balance:
Yes
Wide Dynamic Range (WDR:
True WDR 120dB
Bitrate Control:
CBR/VBR H.264/H.265
IP:
IPv4
LAN:
1000Base-T (1Gbps)
Network resolution:
H.264/H.265: QFHD, 2.1MP, 1080p, 720p, VGA, D1, CIF
Network Web Viewer:
Chrome, Edge, Firefox, Safari on Windows/Mac/Linux
Protocol:
DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP)
Security:
802.1x, Digest authemtication (ID/PW), HTTPS (TLS), IP filtering
Stream Speed:
Up to 30fps at all resolutions
Streaming Capability:
Dual-stream at different rates and resolutions
Video Bitrate:
100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type:
H.264, H.265, MJPEG
Video Management Software:
ONVIF, Spectrum, ExacqVision, Genetec, Milestone
Environmental Operating Humidity:
10-90% (non-condensing)
Environmental Operating Temperature:
-40°F ~ 122°F (-40°C ~ 50°C)
Mounting Accessories (Required/Optional:
Optional. Sold separately
Camera Dimensions (H X W X D:
*Dimensions based on the position of the sun shield cover
Camera Weight:
2.64 lbs (1.2 kg)
Housing:
Bullet
Housing Color:
White
Vandal Rating:
IK10 Rated
IP Rating:
IP67
Materials:
Aluminum die-casting
American wire gauge (AWG:
Cable type #18
Power (Max:
DC12V: 10.2W, 850mA, PoE: 16W
Power Requirements:
Adapter not included, PoE
Warranty:
5 Year Warranty
Product Type:
Bullet
Connectivity:
Wired
Power Type:
PoE
Resolution:
8MP
Night Vision:
IR
Environment Rating:
Outdoor
