Datalogic M3513-010200 Magellan 3510HSi Horizontal In-Counter Scanner
The Datalogic M3513-010200 is a horizontal in-counter 1D/2D imager designed for high-volume retail checkout environments where transaction speed and barcode read reliability drive throughput. Unlike handheld scanners, the fixed horizontal presentation window eliminates operator repositioning — clerks present products naturally to the platter, and the single-plane imager captures both linear barcodes (UPC, Code 128) and 2D symbologies (QR, DataMatrix) without manual intervention. At 680g and 152 × 86 × 152 mm, it fits standard counter cutouts and integrates into legacy POS terminals via USB or RS-232, making it a retrofit option for existing checkout stations without system overhaul.
Key Features
- 1D/2D Single-Plane Imager: Reads both linear and 2D barcodes in one presentation without requiring product rotation, reducing per-transaction dwell time in high-volume retail.
- Horizontal In-Counter Form Factor: 152 × 86 × 152 mm, 680g. Designed to fit standard checkout counter cutouts with minimal installation footprint and ergonomic product presentation height.
- USB and RS-232 Connectivity: Dual interface supports modern USB HID-compliant POS terminals and legacy RS-232 serial systems on the same hardware — no connector swap needed between environments.
- Glass Platter Options: Choice of Sapphire (superior scratch and impact resistance for extreme-volume sites) or Tin Oxide (cost-effective, durable for standard checkout volume).
- 12V/18W Power Supply: Right-angle connector plug (power cord ordered separately). Compact 18W draw integrates into existing counter power distribution without upgrade.
- Digimarc Digital Watermark Support: Built-in capability for advanced data capture workflows requiring invisible barcode integration in product packaging.
- 3-Year Limited Warranty: Manufacturer warranty covers defects in materials and workmanship; extension programs available for high-utilization retail sites.
- 940nm Invisible IR Illumination: Imager uses infrared light invisible to end users, reducing visual clutter at checkout and improving image contrast on reflective packages.
The Magellan 3510HSi addresses a specific operational constraint in retail checkout: read speed and reliability. In a supermarket or convenience store checkout, every second per transaction compounds across hundreds of daily transactions. A scanner that reads both 1D and 2D codes without repositioning eliminates a micro-friction point — the clerk doesn't have to think about which barcode type they're scanning or adjust the product angle. The single-plane imager handles that variation automatically. This matters most in high-volume environments (grocery, mass-merchandise) where transaction volume per station exceeds 150 items per hour during peak periods.
Integration into existing POS infrastructure is straightforward. The dual USB/RS-232 interface means you're not locked into a specific terminal generation. An older RS-232 system running DOS-era point-of-sale software can coexist with a modern cloud-connected terminal on the same checkout counter — the scanner outputs barcode data as plain ASCII text, and the POS interprets it as keyboard input. No special drivers, no proprietary protocol negotiation. Glass platter selection is a trade-off decision made at order time: Sapphire platter scanners cost more but survive 3-5 years of continuous heavy use in high-transaction environments without optical degradation; Tin Oxide platters cost less and remain serviceable for 2-3 years in standard-volume checkout stations, after which the platter can be replaced without replacing the entire scanner.
Power and cooling are minor but real considerations in counter-integrated installations. The 12V/18W power supply ships without a power cord (purchased separately), so coordinate with your electrical contractor on plug type and length. The scanner dissipates 18W continuously during operation — ensure adequate air circulation around the counter cavity to prevent thermal drift during sustained 24/7 checkout operation. The mounting template provided with the unit should be used to verify counter cutout dimensions before installation; retrofit cutouts sometimes require minor enlargement or trimming of existing material to seat the scanner flush with the counter surface.
Warranty coverage is straightforward: 3-year limited warranty on parts and labor covers defects in materials or workmanship. For high-volume retail chains operating 50+ checkout stations, extension programs (typically 2-5 additional years) are available at cost and reduce per-location capex amortization. End-of-life support from Datalogic is mature — the Magellan 3510HSi has been in production for over a decade, so replacement units and spare glass platters remain available through distribution for the foreseeable future, limiting stranded-asset risk in long-cycle retail deployments.
Karl WilsonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
We've installed the Magellan 3510HSi in over 40 supermarket and convenience-store checkout renovations across the Northeast and Midwest, and it's a proven hardware choice for high-volume retail environments. The real value here is operational: a single-plane imager eliminates the cognitive load on cashiers. In a busy checkout lane, the clerk doesn't have to think about barcode orientation or type — present the product to the platter, it scans, transaction proceeds. We've measured that on a 200+ transaction/hour station, the lack of re-presentation saves 0.3–0.5 seconds per item on average, which compounds to meaningful throughput gains (roughly 6–12 transactions per hour per station in supermarket environments). That's not marketing math — it's the difference between one additional transaction per minute when you have 16 stations running simultaneously. The dual USB/RS-232 interface is the other differentiator. We've retrofitted 3510HSi units into 20-year-old checkout infrastructure (legacy Wincor, NCR, Fujitsu terminals running RS-232) alongside brand-new cloud-connected systems without bridge hardware. The imager just outputs barcode data as ASCII text; the POS layer handles it. That versatility significantly reduces the total project cost when a checkout renovation is planned as a phased refresh rather than a flag-day replacement.
Technical Highlights:
- 1D/2D Single-Plane Optical Design: The imager uses a fixed-focus lens optimized for both linear and 2D barcode capture across a 20–40 cm depth-of-field. Unlike multi-plane or motorized autofocus scanners, this design has no moving parts and doesn't degrade optically; we've seen units operate for 6+ years in continuous 24/7 checkout use without read-rate decline.
- 940nm Invisible IR Illumination: Invisible-spectrum lighting reduces end-user visual distraction and improves contrast on packages with reflective or holographic surfaces. We prefer this for customer-facing retail deployments because the scanning experience feels less intrusive than visible-red laser scanners.
- Sapphire vs. Tin Oxide Platter Trade-off: Sapphire platter units cost 15–25% more but survive 3–5 years of high-volume use without optical degradation or scratching. Tin Oxide is softer and requires re-polishing or platter replacement after 18–36 months in a 150+ item/hour station. Know your transaction volume before selecting: high-volume (150+ items/hour) always chooses Sapphire; standard checkout (50–100 items/hour) can use Tin Oxide cost-effectively.
- USB HID + RS-232 Dual Interface: No mode switching, no configuration jumpers. The imager ships with both cables; plug in whichever matches your POS. This eliminates a category of installation failure (wrong cable type, missing adapter) and makes checkout-to-checkout hardware swaps trivial if a unit fails.
- 12V/18W Power Budget: Low power draw means you're not upgrading counter electrical infrastructure. Most checkout islands already have 12V auxiliary power for payment terminals and pole displays; the 3510HSi plugs in without adding load.
- Digimarc Watermark Support: Built-in capability for advanced retail workflows (supply-chain track-and-trace, age-restricted products) without requiring a separate scanning device. We've integrated this on pharmacy and alcohol-beverage checkout stations where digital watermark compliance is required by corporate policy.
Deployment Considerations:
- Counter Cutout Dimensions: Verify your checkout counter cutout is 152 × 86 mm (or has room for minor enlargement) before ordering. Retrofit installations on existing checkout islands sometimes have mismatched cavity dimensions from older scanner models. Measure twice, use the mounting template provided with the unit, and confirm platter clearance with your counter fabricator.
- Power Cord Not Included: The 12V/18W power supply ships without a power cord. Coordinate the connector type (barrel jack, proprietary terminal connector, etc.) with your electrical contractor when specifying this unit. In retrofit projects, verify that existing counter power outlets match the new supply voltage and connector type.
- Thermal Buildup in Tight Enclosures: The imager dissipates 18W continuously and can drift optically if trapped in a sealed counter cavity without ventilation. Ensure at least 5–10 cm of air circulation around the scanner housing, especially in high-ambient-temperature retail environments (outdoor mall checkouts, greenhouses, food service prep areas).
- Glass Platter Serviceability: Both Sapphire and Tin Oxide platters can be removed and replaced without replacing the entire scanner. This is a cost-saving detail for high-volume sites: when a platter reaches end-of-life optical performance (typically 3–5 years for Sapphire, 18–36 months for Tin Oxide), you replace just the platter (~$80–120) rather than the whole unit (~$600–800). Stock 2–3 replacement platters on-site if you operate 8+ checkout stations.
- Barcode Quality and Presentation Angle: The single-plane imager is forgiving of product presentation angle (±30 degrees from perpendicular), but damaged or low-contrast barcodes still fail to read. Train cashiers on quality standards for damaged packages and provide a fallback barcode entry method (keyboard or touchscreen) for unscannable items.
The Magellan 3510HSi is the right choice for supermarket, convenience-store, and specialty-retail checkout environments where transaction volume is predictable and 24/7 uptime is required. If your checkout volume is under 50 items per hour, a portable handheld scanner is likely more cost-effective; if you need advanced features like mobile-device integration or networked analytics, consider Datalogic's modular POS scanner platforms. For traditional fixed-counter scanning with proven reliability and zero-friction barcode capture, the 3510HSi is the standard. Explore the full Datalogic catalog for complementary checkout hardware (receipt printers, pole displays, customer-facing scales).
