Datalogic DSM0492-WA Decoded 2D Scan Engine Module
The Datalogic DSM0492-WA is a compact decoded 2D scan engine module engineered for OEM integration into kiosks, self-service terminals, medical devices, and embedded scanning solutions. Part of the DSE0420 series, this lightweight module delivers high-speed barcode capture with onboard decoding, USB connectivity, and flexible mounting capabilities for enterprise-grade applications.
Key Features
- 2D Imager with 60 fps image capture for rapid scanning operations
- Onboard decoded processing for immediate data validation
- USB connectivity with HID, COM, and Keyboard emulation support
- Compact form factor: 25 x 20 x 30 mm for seamless OEM integration
- Lightweight design at 27 g for space-constrained installations
- Support for all standard 1D and 2D barcode symbologies
- 1-Year Limited Warranty with Datalogic factory support
Technical Specifications
- Scan Type: 2D Imager, 60 fps
- Connectivity: Wired USB (HID, COM, Keyboard)
- Dimensions: 25 x 20 x 30 mm (1.0 x 0.8 x 1.2 in)
- Weight: 27 g (0.06 lb)
- Series: DSE0420
Applications
The DSM0492-WA is ideal for OEM manufacturers requiring decoded 2D scanning in compact, embedded form factors. Common deployments include retail self-checkout kiosks, patient check-in terminals in healthcare facilities, automated package handling systems, and laboratory specimen tracking. The 60 fps capture rate ensures smooth scanning throughput even in high-volume environments.
Enterprise Integration
Organizations standardizing on the DSE0420 platform benefit from consistent hardware performance across multiple facilities, simplified spare parts inventory management, and centralized device configuration. Datalogic's proven support infrastructure and available extended warranty options provide IT teams with cost predictability and operational continuity.
