APC by Schneider Electric Custom for BarcodesInc - 2023-2018714

APC by Schneider Electric 2023-2018714 Concise Descriptor

Overview

The APC by Schneider Electric 2023-2018714 is a purpose-built mounting bracket designed to ensure secure and stable installation of specific APC surveillance devices. This accessory is critical for achieving optimal camera positioning and maintaining system integrity in environments where standard mounting is not feasible or desired. It addresses the need for a robust physical connection between the surveillance hardware and its mounting surface, preventing vibration-induced image degradation and potential device dislodgement.

Compatibility

This bracket is engineered exclusively for use with the following APC by Schneider Electric product families: APC-SMT-2U-UPS series, APC-SMT-3U-UPS series, and APC-SMT-4U-UPS series. Ensure your device model number falls within these specified series before purchase to guarantee correct fit and function.

Installation Notes

Installation requires basic hand tools, including a Phillips head screwdriver and a torque wrench set to 1.5 Nm (13.3 lb-in). Ensure the mounting surface is structurally sound and capable of supporting the combined weight of the bracket and the attached APC device. Use only the provided M4x8mm screws for securing the bracket to the device, and M6x12mm screws for attaching the bracket to the mounting surface. Do not overtighten fasteners.

What's in the Box

• 1x APC by Schneider Electric 2023-2018714 Mounting Bracket
• 4x M4x8mm Device Mounting Screws
• 4x M6x12mm Surface Mounting Screws
