Panduit CTAP2/0-2-X Copper Lug

Overview

The Panduit CTAP2/0-2-X is a copper compression lug designed for terminating 1/0 through 2/0 AWG stranded copper conductors. It provides a secure, reliable electrical connection essential for power distribution systems, particularly in environments where vibration or thermal cycling could compromise less robust connections. This lug is engineered for direct burial applications, offering corrosion resistance and long-term performance in demanding conditions. The CTAP2/0-2-X is a critical component for ensuring the integrity of electrical circuits in industrial automation, power generation, and commercial building infrastructure.

Compatibility

This lug is specified for use with 1/0 AWG (53.5 mm²) through 2/0 AWG (67.4 mm²) stranded copper conductors. It is designed to be crimped using Panduit's specified crimping tools and die sets, ensuring a permanent, low-resistance connection. Compatibility extends to systems requiring direct burial rated connectors for underground power distribution or grounding applications.

Installation Notes

For optimal performance and safety, the CTAP2/0-2-X lug must be crimped using Panduit's recommended hydraulic crimping tools and the correct die set for the conductor size. Consult Panduit's installation documentation for precise torque specifications and recommended crimp locations. Ensure the conductor is clean and free of debris before insertion. The lug is rated for direct burial, meaning it can be installed underground without additional protective enclosures, provided proper crimping and insulation (if required by code) are applied.
