Cradlepoint 170716-001 12VDC Power Supply 1.5M Cable
Overview
The Cradlepoint 170716-001 is a 12VDC regulated power supply built for field-deployed ruggedized router platforms. It delivers stable 12V DC output via a 1.5-meter cable terminated in a 2x2 4-pin Molex connector — the standard power interface on Cradlepoint R-series, IBR, and E-series platforms. Use this when you're replacing a failed PSU or setting up a remote site installation where the original supply is unavailable or damaged. The 1.5M cable length gives you flexibility in cabinet or wall-mount routing without requiring additional extension harnesses.
Compatibility
The 170716-001 is designed for Cradlepoint R2100 Series, R1900 Series, IBR1700, R980, R920 Series, S700 Series, S400, IBR200, E300, E100, E102, and discontinued models (IBR900, IBR600C, IBR600, IBR600B, IBR350). Verify your router's power connector is the 2x2 4-pin Molex type before ordering — mismatched connectors will not mate. If you're unsure which supply your unit requires, reference the router's datasheet or serial-number-based compatibility list from the manufacturer.
Installation Notes
Operating temperature range is -20°C to 60°C, so this supply is suitable for both heated indoor shelters and unheated outdoor enclosures in temperate climates. The line cord is North America Type A (NEMA 5-15P), making it compatible with standard US/Canada wall outlets. Do not expose the cable to standing water or submerged environments — this is a field-grade but not submersible supply. For extended outdoor installations, use weatherproof conduit or cable trays to shield the 1.5M lead from UV and abrasion.
What's in the Box
- 1x Cradlepoint 12VDC power supply with 1.5M cable and 2x2 4-pin Molex connector
