Panduit PUP6004BU-WLPZ TX6000 Cat 6 UTP Plenum Copper Cable - Blue, 1000 ft

The Panduit TX6000 Cat 6 UTP copper cable delivers the high-performance infrastructure commercial integrators need for IP surveillance, access control, and converged network installations. This 1000-foot bulk cable spool features 23 AWG solid copper conductors with plenum-rated CMP jacket, meeting NEC Article 800 requirements for air-handling spaces without conduit. The cable's cross-divider construction maintains pair geometry throughout long pulls, ensuring consistent 250 MHz performance and headroom for PoE, PoE+, and PoE++ powered devices. Blue jacket color-coding simplifies network segmentation and troubleshooting in multi-system environments.

Key Features

• Plenum-rated CMP jacket certified for installation in air-handling spaces, drop ceilings, and HVAC plenums without conduit
• 23 AWG solid copper conductors provide low DC resistance for reliable PoE power delivery up to 100 meters
• Cross-divider pair separator maintains geometry and minimizes crosstalk across the full 1000-foot pull length
• Cat 6 performance verified to 250 MHz exceeds TIA-568.2-D and ISO/IEC 11801 Class E channel requirements
• FEP/polyolefin insulation system delivers low smoke and flame spread ratings required by fire marshal inspection
• Blue jacket color enables instant identification of security network segments or VLAN assignment in structured cabling systems
• 1000-foot spool length reduces mid-run splices and supports single-pull horizontal runs up to 295 feet (90 meters)
• Pan-Net sub-brand indicates Panduit's copper systems warranty and technical support coverage

The TX6000 cable family addresses the real-world demands of IP camera installations where integrators must balance code compliance, long-term bandwidth headroom, and installation labor costs. The 23 AWG conductor gauge is the sweet spot for commercial security work—heavy enough to deliver reliable PoE power across 100-meter horizontal runs without voltage drop issues that plague 24 AWG economy cables, yet flexible enough for tight-radius pulls through existing pathways. The cross-divider construction is critical in long cable runs where pair-to-pair crosstalk degrades signal integrity; Panduit's design maintains the required pair separation geometry even when the cable is bent, twisted, or compressed during installation. The CMP plenum rating uses FEP and polyolefin materials that produce minimal smoke and toxic gas when exposed to fire, meeting the stringent flame and smoke ratings required for cables installed above suspended ceilings or in HVAC air return spaces. This eliminates the cost and labor of running conduit in these areas, a significant advantage in tenant improvement and retrofit projects where ceiling access is limited.

For integrators deploying modern IP surveillance systems, this cable provides the performance foundation needed for multi-megapixel cameras with H.265 compression, two-way audio, and edge analytics. Cat 6 cabling delivers 1 Gbps Ethernet speeds at distances up to 100 meters (328 feet), with substantial margin above the 100 Mbps Fast Ethernet baseline used by most IP cameras today. This headroom protects the infrastructure investment when clients upgrade camera resolutions or add bandwidth-intensive features years after initial installation. The cable fully supports IEEE 802.3af PoE (15.4W), 802.3at PoE+ (30W), and 802.3bt PoE++ (up to 60W on Type 3), covering the power requirements for PTZ cameras, multi-sensor panoramic cameras, door controllers with electric locks, and PoE-powered network switches. The solid copper conductors minimize DC resistance compared to copper-clad aluminum (CCA) alternatives, ensuring consistent power delivery even on maximum-length 90-meter horizontal runs where voltage drop is most critical. Blue jacket color-coding is standard practice in commercial security installations for visually distinguishing the IP surveillance network from IT data networks, guest Wi-Fi, or building automation systems sharing the same cable tray infrastructure.

This cable complies with TIA-568.2-D structured cabling standards for Category 6 performance, UL listing for CMP plenum applications, and NEC Article 800 fire safety requirements. Panduit's TX6000 system is backed by comprehensive third-party verification testing and a 25-year system warranty when installed with Panduit connectivity hardware. For integrators who need to document compliance on projects subject to fire marshal inspection, building code enforcement, or client specification review, Panduit provides certified test data and material safety documentation that budget-tier cable vendors often cannot supply. The 1000-foot spool length is optimized for commercial horizontal cabling where most runs fall in the 100-250 foot range—long enough to minimize waste and mid-run splices, compact enough for one technician to handle on a pull cart without a second helper.
