Panduit PUP6C04WH-WLPZ Cat 6 Plenum UTP Cable 1000ft

Panduit PUP6C04WH-WLPZ Cat 6 Plenum UTP Cable

The Panduit PUP6C04WH-WLPZ delivers 1000 feet of Cat 6 UTP structured cabling engineered for commercial IP camera backbones, access control runs, and PoE device installations. This 23 AWG solid-conductor cable carries CMP plenum fire rating for air-handling spaces, supports Gigabit Ethernet and PoE++ power delivery, and ships in a pull-box format that reduces labor on multi-drop projects. White PVC jacket blends into finished ceilings and trim-out zones where visible runs matter.

Key Features

• CMP plenum fire rating for above-ceiling and HVAC pathway compliance per NEC Article 770
• Cat 6 performance verified to 250 MHz for Gigabit Ethernet and 10GBASE-T short-reach applications
• 23 AWG solid copper conductors rated for permanent backbone installations and PoE++ (IEEE 802.3bt Type 4, 100W) power delivery
• U/UTP unshielded twisted-pair construction balances cost and EMI rejection in typical commercial environments
• 1000-foot pull box reduces splice points and speeds installation on campus projects, multi-tenant buildings, and warehouse deployments
• White jacket color for professional finished appearance in open ceilings, cable trays, and conduit

Panduit Pan-Net Cat 6 cable uses four-pair 23 AWG solid bare copper conductors in unshielded twisted-pair geometry. The cable meets TIA-568.2-D Cat 6 channel and permanent link performance when terminated with Panduit Mini-Com or similar Cat 6 connectors. Bandwidth extends to 250 MHz with <35 dB crosstalk margins, supporting 1000BASE-T (1 Gbps) at full 100-meter distance and 10GBASE-T (10 Gbps) at distances up to 55 meters. This performance tier handles IP camera streams (including 4K and multi-sensor models), VoIP handsets, wireless access points, and access control panels without requiring shielded or augmented Cat 6A infrastructure.

The CMP jacket compound meets NEC Article 770 plenum requirements with low smoke and flame-spread characteristics suitable for installation in air-handling spaces, above drop ceilings, and HVAC return plenums. This rating eliminates the need for conduit in many commercial and institutional projects, reducing material cost and simplifying retrofit work in occupied buildings. Solid 23 AWG conductors deliver DC loop resistance under 9.4 ohms per 100 meters, supporting PoE+ (25.5W per IEEE 802.3at) and PoE++ (up to 100W per IEEE 802.3bt Type 4) without exceeding temperature rise limits. Integrators installing high-power PTZ cameras, multi-sensor arrays, or outdoor IR models can run power and data on a single cable, eliminating AC outlets at device locations and reducing installation labor by 30-40% compared to separate power drops.

The 1000-foot pull box ships as a single carton, enabling long runs between telecom closets and endpoint clusters without mid-span splices. This length accommodates typical horizontal cabling distances in commercial buildings (90-meter permanent link plus 10 meters of patch cords) with margin for routing through cable trays, J-hooks, and conduit bends. White jacket color provides a clean finished appearance in exposed ceilings, open office environments, and retail spaces where aesthetic concerns limit the use of blue or gray cable. The unshielded construction simplifies grounding compared to shielded alternatives and maintains flexibility for pulling through crowded pathways. Panduit backs the cable with technical support and compatibility certification across the Pan-Net structured cabling ecosystem, ensuring reliable termination with Panduit jacks, patch panels, and keystone modules.

This cable suits IP surveillance projects where plenum rating is code-required, PoE power delivery is standard, and Gigabit performance is sufficient for current camera generations. Integrators working on multi-building campuses, healthcare facilities, K-12 schools, and office retrofits will find the 1000-foot length and white jacket reduce both material waste and visible infrastructure. The Cat 6 performance tier offers a cost-effective middle ground between legacy Cat 5e (insufficient for future PoE++ loads) and premium Cat 6A (overkill for most camera and access control applications). For installations requiring EMI immunity near motors or fluorescent ballasts, consider Panduit shielded alternatives; for 10 Gbps backbone runs, specify Cat 6A; for standard commercial IP camera and access control deployments in plenum spaces, the PUP6C04WH-WLPZ delivers code-compliant performance at competitive cost.
