Hanwha S204S-96TB vs Speco Technologies SB01M: Specification Comparison
Both the Hanwha WRR-P-S204S-96TB and the Speco Technologies SB01M are 256-channel rackmount NVRs aimed at large-scale IP camera deployments — the same device class and channel tier a systems integrator or IT buyer would directly cross-shop. The Hanwha is a 2U enterprise-grade appliance with a defined storage and compute configuration, while the Speco is a rack-mounted unit with modular, scalable storage and a lighter processor platform. The comparison below covers the three axes most critical to a 256-channel NVR purchase: compute and storage capacity, physical build and environmental tolerance, and integration and codec support.
In This Guide
- Which NVR delivers more compute power and usable storage capacity for 256-channel recording?
- How do these two units compare on physical build quality, environmental ratings, and deployment conditions?
- Which unit offers broader camera integration, codec support, and management capabilities?
- Which should you choose: the S204S-96TB or the SB01M?
- Side-by-Side Specs
- FAQ
Which NVR delivers more compute power and usable storage capacity for 256-channel recording?
The Hanwha S204S-96TB is specified with an Intel Xeon 4410Y processor, 16GB DDR4 RAM, 96TB raw storage (72TB usable under RAID 5) across 12 hot-swap 3.5" HDDs, and a validated sustained recording throughput of 470 Mbps. It also includes dual 480GB SSDs in RAID 1 for the OS, an 8GB cache, and supports RAID 0, 1, 5, and 6 configurations. These are explicit, measured figures from the provided specification set.
The Speco SB01M lists a processor field that references three distinct processor options — Intel Jasper Lake N5095, Intel Core i5, and Intel Core E-2200 — without specifying which is actually installed in the shipping unit. RAM is listed as 8GB DDR4, expandable to 128GB. Storage is described only as 'modular, scalable' with no raw capacity, usable capacity, RAID level, or throughput figure provided in the supplied specifications.
For buyers who require verified throughput headroom and a defined RAID storage configuration at time of purchase, the Hanwha's 470 Mbps validated bandwidth and 72TB usable capacity are concrete planning numbers. The Speco's storage and processor specifications are insufficiently defined in the provided data to draw an equivalent comparison on these dimensions.
How do these two units compare on physical build quality, environmental ratings, and deployment conditions?
The Hanwha S204S-96TB is a 2U rackmount unit weighing 80 lb, with dimensions of 39.0 × 27.0 × 14.0 in. It carries IP66 and IK10 ratings and a NEMA 4X rating, with a specified operating temperature range of -40°C to +55°C. Country of origin is listed as Mexico. These environmental ratings are atypical for a pure rackmount NVR and may reflect shared spec fields from the broader product record; buyers should verify against the datasheet at /content/product-datasheets/WRR-P-S204S-96TB.pdf.
The Speco SB01M weighs 1.01 lb, with dimensions of 16.15 × 12.6 × 10.16 in, and is listed with rack mount type. No IP rating, IK rating, NEMA rating, or operating temperature range is provided in the supplied specifications. The housing color is listed as White and a separate 'Color' field is listed as Clear.
The 79-lb weight difference between the two units is significant for rack planning and physical installation. The Hanwha's NEMA 4X and IP66/IK10 ratings — if confirmed applicable to this NVR unit — would indicate suitability for harsher environments. No equivalent environmental rating data exists in the Speco specification set to make a parallel assessment.
Which unit offers broader camera integration, codec support, and management capabilities?
The Hanwha S204S-96TB supports 256 concurrent IP cameras from both Wisenet-native cameras and ONVIF-compliant third-party devices. Codec support is explicitly listed as H.265, H.264, and MJPEG. The unit also includes analytics capability (People Counting), audio input, and the bundle IDs suggest integration with complementary Hanwha ecosystem components. PoE++ (802.3bt) is specified in the product record, though again buyers should confirm this applies at the NVR level versus an associated switch.
The Speco SB01M is specified as ONVIF Profile compliant and supports 256 IP camera channels. Codec support is described as 'adaptive bitrate recording' with no explicit codec standard (H.265, H.264, etc.) named in the provided specifications. Remote access and configuration are listed under management. The operating system is Linux. PoE is listed as 802.3af. Memory is expandable to 128GB, which is relevant for high-channel software processing loads.
The Hanwha unit names specific codec standards (H.265, H.264, MJPEG) and identifies both Wisenet-native and ONVIF integration paths, which is useful for multi-vendor or Hanwha-centric deployments. The Speco's 'adaptive bitrate' descriptor does not map to a named codec standard in the provided data, limiting direct comparison. The Speco's RAM expandability to 128GB is a notable hardware advantage if the platform relies on software-defined recording pipelines.
Which should you choose: the S204S-96TB or the SB01M?
Our take: The S204S-96TB is the stronger choice when a buyer needs a fully defined, high-throughput enterprise NVR with explicit storage and compute specifications at time of purchase. It delivers a validated 470 Mbps recording bandwidth versus no stated throughput figure for the SB01M; 72TB usable RAID 5 capacity across 12 hot-swap drives versus the SB01M's unquantified 'modular, scalable' storage; and an Intel Xeon 4410Y with 16GB DDR4 versus the SB01M's ambiguous processor listing (three options cited, none confirmed as shipped) with 8GB DDR4. The SB01M's RAM expandability to 128GB and its lighter 1.01 lb chassis may suit deployments where the NVR platform is software-defined and storage is handled externally. Buyers committed to the Hanwha Wisenet ecosystem gain native camera integration on top of ONVIF. Buyers running a mixed-vendor environment with external storage infrastructure should verify the Speco's actual shipped processor and storage configuration directly with the manufacturer before specifying.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Hanwha S204S-96TB | Speco Technologies SB01M |
|---|---|---|
| Device Type | 2U Rackmount NVR | Rackmount NVR |
| Max IP Camera Channels | 256 (Wisenet + ONVIF) | 256 (ONVIF) |
| Processor | Intel Xeon 4410Y | Intel Jasper Lake N5095 / Core i5 / Core E-2200 (unspecified shipped config) |
| RAM | 16GB DDR4 | 8GB DDR4 (expandable to 128GB) |
| Raw Storage Capacity | 96TB | — |
| Usable Storage (RAID 5) | 72TB | — |
| Storage Configuration | 12× hot-swap 3.5" HDD; RAID 0/1/5/6; 8GB cache | Modular, scalable (no detail provided) |
| OS Drive | Dual 480GB SSD (RAID 1) | — |
| Sustained Recording Throughput | 470 Mbps | — |
| Codec Support | H.265, H.264, MJPEG | Adaptive bitrate (no named standard) |
| Operating System | — | Linux |
| PoE Spec Listed | PoE++ (802.3bt) | PoE (802.3af) |
| Audio | Audio input | Audio input |
| Warranty | 5-year | 3-year |
| Weight | 80 lb | 1.01 lb |
| Dimensions (in) | 39.0 × 27.0 × 14.0 | 16.15 × 12.6 × 10.16 |
Frequently Asked Questions
Which should you choose: the S204S-96TB or the SB01M?
The S204S-96TB is the stronger choice when a buyer needs a fully defined, high-throughput enterprise NVR with explicit storage and compute specifications at time of purchase. It delivers a validated 470 Mbps recording bandwidth versus no stated throughput figure for the SB01M; 72TB usable RAID 5 capacity across 12 hot-swap drives versus the SB01M's unquantified 'modular, scalable' storage; and an Intel Xeon 4410Y with 16GB DDR4 versus the SB01M's ambiguous processor listing (three options cited, none confirmed as shipped) with 8GB DDR4. The SB01M's RAM expandability to 128GB and its lighter 1.01 lb chassis may suit deployments where the NVR platform is software-defined and storage is handled externally. Buyers committed to the Hanwha Wisenet ecosystem gain native camera integration on top of ONVIF. Buyers running a mixed-vendor environment with external storage infrastructure should verify the Speco's actual shipped processor and storage configuration directly with the manufacturer before specifying.
Is the S204S-96TB or SB01M better for larger deployments needing defined storage capacity?
Based on the provided specifications, the S204S-96TB is the only unit with a stated storage figure: 96TB raw, 72TB usable under RAID 5, with 12 hot-swap 3.5" HDD bays and a validated 470 Mbps sustained throughput. The SB01M's storage is described as 'modular, scalable' with no capacity, RAID configuration, or throughput number specified in the provided data. If a defined, on-board storage capacity is a planning requirement, the S204S-96TB provides that information; the SB01M does not in the available spec set.
Does the SB01M support the same camera brands and codecs as the S204S-96TB?
Both units list ONVIF compatibility, which provides baseline interoperability with third-party IP cameras. The S204S-96TB additionally specifies Wisenet-native camera support and explicitly names H.265, H.264, and MJPEG codecs. The SB01M lists 'adaptive bitrate recording' but does not name specific codec standards (H.265, H.264, etc.) in the provided specifications. Buyers integrating Hanwha Wisenet cameras will find native support documented only on the S204S-96TB.
Which unit is easier to install in a standard server rack given its size and weight?
The Speco SB01M, at 1.01 lb and 16.15 × 12.6 × 10.16 in, is significantly lighter and more compact than the Hanwha S204S-96TB, which weighs 80 lb and measures 39.0 × 27.0 × 14.0 in as a 2U appliance. The S204S-96TB's weight requires appropriate rack support hardware and likely a two-person installation. No rack unit height (RU) is listed for the SB01M in the provided specifications. Buyers should verify rack unit requirements for both units with their respective datasheets before finalizing rack layout.
