Code Blue CB2A00038 IP5000s PoE Wall Mount

Overview

The Code Blue CB2A00038 is a wall-mounted stainless steel enclosure built for outdoor help point and emergency communication deployments. Constructed from 0.078" stainless steel, this mount houses the IP5000s system and protects electronics from weather, dust, and corrosion — critical for parking structures, perimeter gates, loading docks, and campus security stations where vandalism and environmental exposure are routine concerns. The CB2A00038 integrates directly with Code Blue's IA4100 analog speakerphone and LS1000 VoIP speakerphone modules, enabling wall-mounted emergency call stations that work in wet, freezing, and high-UV environments.

Compatibility

The CB2A00038 is designed for Code Blue's 2 Series Analog product family, specifically the IP5000s help point system. Compatible with IA4100 analog full-duplex speakerphone modules and LS1000 VoIP speakerphones. Requires 12–24V AC/DC power input (PoE or traditional AC/DC supply). Integrates into existing emergency call networks and physical security infrastructure without modification to control logic or switching.

Installation Notes

Built to NEMA 4 environmental rating and designed to ADA specifications — confirm final mounting height and accessibility with local code before installation. Stainless steel construction resists salt spray and UV degradation, but mounting surface must support 25 lbs. Wall mounting only; does not support ceiling or pole installation. Accepts 12–24V AC/DC via standard terminal blocks. Beacon/strobe module included for visual notification. Dimensions: 29.79" H × 11.90" W × 4" D. Site survey should confirm line of sight to intercom stations and VoIP network proximity if using LS1000 module.
